Dahua Technology Lite IPC-HDW3441T-ZAS Bruksanvisning

Dahua Technology Sikkerhetskamera Lite IPC-HDW3441T-ZAS

Les nedenfor 📖 manual på norsk for Dahua Technology Lite IPC-HDW3441T-ZAS (17 sider) i kategorien Sikkerhetskamera. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/17

Eyeball Network Camera

Quick Start Guide

V1.0.0

ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.

Foreword I

Foreword

General

This manual introduces the functions, installation, and operations of the camera.

Safety Instructions

The following categorized signal words with dened meaning might appear in the manual.

Signal Words

Meaning

WARNING

Indicates a medium or low potential hazard which, if not avoided,

could result in slight or moderate injury.

CAUTION

Indicates a potential risk which, if not avoided, could result in

property damage, data loss, lower performance, or unpredictable

result.

NOTE

Provides additional information as the emphasis and supplement

to the text.

Revision History

Version

Revision Content

Release Time

V1.0.0

First release.

May 2019

Privacy Protection Notice

As the device user or data controller, you might collect personal data of other such as face,

ngerprints, car plate number, Email address, phone number, GPS and so on. You need to be

in compliance with the local privacy protection laws and regulations to protect the legitimate

rights and interests of other people by implementing measures include but not limited to:

providing clear and visible identication to inform data subject the existence of surveillance

area and providing related contact.

About the Manual

 The manual is for reference only. If there is inconsistency between the manual and the

actual product, the actual product shall prevail.

 We are not liable for any loss caused by the operations that do not comply with the manual.

 The manual would be updated according to the latest laws and regulations of related

regions. For detailed information, see the paper manual, CD-ROM, QR code or our oicial

website. If there is inconsistency between paper manual and the electronic version, the

electronic version shall prevail.

 All the designs and software are subject to change without prior written notice. The product

updates might cause some dierences between the actual product and the manual. Please

Foreword II

contact the customer service for the latest program and supplementary documentation.

 There still might be deviation in technical data, functions and operations description, or

errors in print. If there is any doubt or dispute, please refer to our nal explanation.

 Upgrade the reader software or try other mainstream reader software if the manual (in PDF

format) cannot be opened.

 All trademarks, registered trademarks and the company names in the manual are the

properties of their respective owners.

 Please visit our website, contact the supplier or customer service if there is any problem

occurred when using the device.

 If there is any uncertainty or controversy, please refer to our nal explanation.

Produkspesifikasjoner

Merke:	Dahua Technology
Kategori:	Sikkerhetskamera
Modell:	Lite IPC-HDW3441T-ZAS
Vekt:	685 g
Høyde:	108.3 mm
Støttede mobile operativsystemer:	Android, iOS
Bluetooth:	Nei
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	2688 x 1520 piksler
Videokomprimeringsformater:	H.264, H.265, M-JPEG
Diameter:	122 mm
Strømkildetype:	DC, PoE
Antall kameraer:	1
LED-type:	IR
Pakkevekt:	828 g
Strømforbruk (maks.):	8.3 W
Sertifisering:	CE-LVD: EN60950-1\nCE-EMC: 2014/30/EU\nFCC: 47 CFR FCC 15, B\nUL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Innebygd mikrofon:	Ja
Internminne:	512 MB
Hvitbalanse:	Auto, Manual, Natural, Outdoor
Nettleser:	Ja
Støyreduksjon:	Ja
Nettverksstandard:	IEEE 802.3af
Antall brukere:	20 bruker(e)
Støttede nettverksprotokoller:	IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP
ROM-kapasitet:	128 MB
Progressiv skanning:	Ja
Rotasjonsvinkel:	360 °
Antall linser:	1
Antall sensorer:	1
Videostreaming:	Ja
Antall effektive piksler (H x V):	2688 x 1520 piksler
Wide Dynamic Range (WDR):	Ja
Atferdsanalyse:	Inntrengingsdeteksjon
Linsesynsvinkel, horisontal:	104 °
Støyreduksjonsteknologi:	3D-støyreduksjon
Linsesynsvinkel, vertikal:	55 °
Bildefrekvens:	30 fps
Sensortype:	CMOS
Produktfarge:	Hvit
Vippevinkelområde:	0 - 78 °
Minnekortenhet:	MicroSD (TransFlash)
Støttede grafikkoppløsninger:	352 x 240,352 x 288,704 x 480,704 x 576,1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),2304 x 1296,2688 x 1520
Brennviddeområde:	2.7 - 13.5 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	-30 - 60 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 60 °C
Innebygd kortleser:	Ja
Lukkerhastighet:	1/3 - 1/100000 s
nattsyn:	Ja
Formfaktor:	Kuppel
CCD-sensorstørrelse:	1/3 "
Modell/Type:	IP-sikkerhetskamera
Kroppsmateriale:	Metall
Innebygd harddisk:	Nei
Panoreringsomfang:	0 - 360 °
Objektivets synsvinkel, diagonal:	124 °
Internasjonal beskyttelses (IP)-kode:	IP67
Bithastighetskontroll:	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Minimumsbelysning:	0.005 lx
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Raskt Ethernet
Relativ luftfuktighet under drift (H-H):	0 - 95
Støttede plasseringer/plasseringer som kan benyttes:	Utendørs
Montasjetype:	Tak/Vegg
Totale megapiksler:	4 MP
Maksimal størrelse på hukommelseskort:	256 GB
Webbasert administrasjon:	Ja
DC-ut, volt:	12
Region of Interest (ROI)-koding:	Ja
Privacy maske:	Ja
Effektiv distanse for nattsyn:	40 m
Avstandsdeteksjon (bred):	64 m
Observere aavstand (bred):	25.6 m
Gjenkjenne avstand (bred):	12.8 m
Avstandsidentifikasjon (bred):	6.4 m
Maksimal blenderåpning:	1.5
Panoreringskontroll:	Ja
Vippekontroll:	Ja
Stemmekodekser:	G.711Mu, G.711a, G.726
Intelligent Video Surveillance (IVS)-systemfunksjoner:	Snubletråd
Videobasert bevegelsesdeteksjon:	Ja
Baklyskompensasjon (BLC):	Ja
Highlight Compensation (HLC):	Ja
Vinningskontrolltype (gain):	Automatisk/Manuell
Kamelukkertype:	Elektronisk
Nærmeste fokuseringsavstand:	0.8 m
Antall lysende LED:	2
Avstandsdeteksjon (tele):	222 m
Observere avstand (tele):	88.8 m
Gjenkjenne avstand (tele):	44.4 m
Avstandsidentifikasjon (tele):	22.2 m
Justering av lukkerhastighet:	Automatisk/Manuell
