Dahua Technology Lite HAC-HDBW1200E Bruksanvisning

Dahua Technology Sikkerhetskamera Lite HAC-HDBW1200E

Les nedenfor 📖 manual på norsk for Dahua Technology Lite HAC-HDBW1200E (19 sider) i kategorien Sikkerhetskamera. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/19

HDCVI

Dome Camera Lite

User’s Manual

V1.0.0

Foreword I

Foreword

General

This user’s manual (hereinafter referred to be "the Manual") introduces the functions,

installation, and operations of the camera.

Safety Instructions

The following categorized signal words with defined meaning might appear in the Manual.

Signal Words

Meaning

Indicates a medium or low potential hazard which, if not avoided,

could result in slight or moderate injury.

Indicates a potential risk which, if not avoided, could result in

property damage, data loss, lower performance, or unpredictable

result.

Provides methods to help you solve a problem or save you time.

Provides additional information as the emphasis and supplement

to the text.

Revision History

No.

Version

Revision Content

Release Time

V1.0.0

First Release.

June 8, 2018

Privacy Protection Notice

As the device user or data controller, you might collect personal data of others' such as face,

fingerprints, car plate number, Email address, phone number, GPS and so on. You need to be

in compliance with the local privacy protection laws and regulations to protect the legitimate

rights and interests of other people by implementing measures include but not limited to:

providing clear and visible identification to inform data subject the existence of surveillance

area and providing related contact.

About the Manual

 The Manual is for reference only. If there is inconsistency between the Manual and the

actual product, the actual product shall prevail.

 We are not liable for any loss caused by the operations that do not comply with the Manual.

 The Manual would be updated according to the latest laws and regulations of related

regions. For detailed information, see the paper Manual, CD-ROM, QR code or our official

website. If there is inconsistency between paper User's Manual and the electronic version,

the electronic version shall prevail.

Foreword II

 All the designs and software are subject to change without prior written notice. The product

updates might cause some differences between the actual product and the Manual. Please

contact the customer service for the latest program and supplementary documentation.

 There still might be deviation in technical data, functions and operations description, or

errors in print. If there is any doubt or dispute, please refer to our final explanation.

 Upgrade the reader software or try other mainstream reader software if the Guide (in PDF

format) cannot be opened.

 All trademarks, registered trademarks and the company names in the Manual are the

properties of their respective owners.

 Please visit our website, contact the supplier or customer service if there is any problem

occurred when using the device.

 If there is any uncertainty or controversy, please refer to our final explanation.

Produkspesifikasjoner

Merke:	Dahua Technology
Kategori:	Sikkerhetskamera
Modell:	Lite HAC-HDBW1200E
Vekt:	310 g
Høyde:	81 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	1920 x 1080 piksler
Diameter:	109.9 mm
Strømkildetype:	DC
Antall kameraer:	1
LED-type:	IR
Pakkevekt:	450 g
Strømforbruk (maks.):	3.4 W
Sertifisering:	CE (EN55032, EN55024, EN50130-4)\nFCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)\nUL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Hvitbalanse:	Auto, Manual
Støyreduksjon:	Ja
Dag/natt-modus:	Ja
Antall linser:	1
Digital Wide Dynamic Range (DWDR):	Ja
Støyreduksjonsteknologi:	Ultra 2D støyreduksjon
Smart IR:	Ja
Synsfelt:	87.5 °
Bildefrekvens:	60 fps
Sensortype:	CMOS
Produktfarge:	Hvit
Vippevinkelområde:	0 - 65 °
Støttede videofunksjoner:	720p, 1080p
Driftstemperatur (T-T):	-40 - 60 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 60 °C
Lukkerhastighet:	1/30 - 1/100000 s
nattsyn:	Ja
IK-kode:	IK10
Formfaktor:	Kuppel
CCD-sensorstørrelse:	1/2.7 "
Signal-til-støy-forhold (SNR):	65 dB
Innebygd harddisk:	Nei
Panoreringsomfang:	0 - 355 °
Internasjonal beskyttelses (IP)-kode:	IP67
Minimumsbelysning:	0.02 lx
Støttede plasseringer/plasseringer som kan benyttes:	Inne & Ute
Montasjetype:	Tak
Totale megapiksler:	2 MP
DC-ut, volt:	12
Effektiv distanse for nattsyn:	30 m
Fast fokalobjektiv:	3.6 mm
Maksimal blenderåpning:	1.85
Baklyskompensasjon (BLC):	Ja
Highlight Compensation (HLC):	Ja
Fast fokus:	Ja
Nærmeste fokuseringsavstand:	0.9 m
Antall lysende LED:	12
Avstandsidentifikasjon:	5 m
Avstandsdeteksjon:	53 m
Observere avstand:	21 m
Gjenkjenne avstand:	11 m
