Side 1/21

IR Bullet Network Camera

Quick Start Guide

V1.0.0

ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD

Foreword I

Foreword

General

This Quick Start Guide (hereinafter referred to be "the Guide") introduces the functions,

installation and operations of the camera.

Safety Instructions

The following categorized signal words with defined meaning might appear in the guide.

Signal Words

Meaning

Indicates a medium or low potential hazard which, if not avoided,

could result in slight or moderate injury.

Indicates a potential risk which, if not avoided, may result in

property damage, data loss, lower performance, or unpredictable

result.

Provides additional information as the emphasis and supplement

to the text.

Revision History

No.

Version

Revision Content

Release Date

V1.0.0

First release.

2018.03

Protect Privacy Notice

As the device user or data controller, you might collect personal data of others' such as face,

fingerprints, car plate number, Email address, phone number, GPS and so on. You need to be

in compliance with the local privacy protection laws and regulations to protect the legitimate

rights and interests of other people by implementing measures include but not limited to:

providing clear and visible identification to inform data subject the existence of surveillance

area and providing related contact.

About this Guide

 The Guide is for reference only. If there is inconsistency between the Guide and the actual

product, the actual product shall prevail.

 We are not liable for any loss caused by the operations that do not comply with the Guide.

 The Guide would be updated according to the latest laws and regulations of related

regions. For detailed information, see the paper Quick Start Guide, CD-ROM, QR code or

our official website. If there is inconsistency between paper User's Guide and the electronic

version, the electronic version shall prevail.

Foreword II

 All the designs and software are subject to change without prior written notice. The product

updates might cause some differences between the actual product and the Guide. Please

contact the customer service for the latest program and supplementary documentation.

 There still might be deviation in technical data, functions and operations description, or

errors in print. If there is any doubt or dispute, please refer to our final explanation.

 Upgrade the reader software or try other mainstream reader software if the Guide (in PDF

format) cannot be opened.

 All trademarks, registered trademarks and the company names in the Guide are the

properties of their respective owners.

 Please visit our website, contact the supplier or customer service if there is any problem

occurred when using the device.

 If there is any uncertainty or controversy, please refer to our final explanation.

Produkspesifikasjoner

Merke:	Dahua Technology
Kategori:	Sikkerhetskamera
Modell:	Pro IPC-HFW5541T-AS-PV
Vekt:	950 g
Dybde:	159 mm
Høyde:	117.9 mm
Støttede mobile operativsystemer:	Android, iOS
Bruksanvisning:	Ja
Bluetooth:	Nei
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	2688 x 1520 piksler
Videokomprimeringsformater:	H.264, H.264+, H.265, H.265 Pro, H.265 Pro+, H.265+
Strømkildetype:	AC, DC, PoE
Antall kameraer:	1
LED-type:	IR
Hvitbalanse:	Auto, Lamp, Manual, Natural, Outdoor
Nettleser:	Ja
Støyreduksjon:	Ja
Nettverksstandard:	IEEE 802.1x
Antall brukere:	20 bruker(e)
Støttede nettverksprotokoller:	IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP ;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP ;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;SNMP
Progressiv skanning:	Ja
Rotasjonsvinkel:	355 °
Antall linser:	1
Antall sensorer:	1
Videostreaming:	Ja
Bevegelsessensor:	Ja
Antall effektive piksler (H x V):	2688 x 1520 piksler
Personvern:	Ja
AC-inngangsspenning:	24 V
Linsesynsvinkel, horisontal:	43 °
Lydinngangskanaler:	1 kanaler
Digital Wide Dynamic Range (DWDR):	Ja
Støyreduksjonsteknologi:	3D-støyreduksjon
Linsesynsvinkel, vertikal:	23 °
Smart IR:	Ja
Bildefrekvens:	30 fps
Sensortype:	CMOS
Støttede lydformater:	AAC
Produktfarge:	Hvit
Vippevinkelområde:	0 - 65 °
Minnekortenhet:	MicroSD (TransFlash)
Støttede grafikkoppløsninger:	352 x 240,352 x 288,640 x 480 (VGA),704 x 576,1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),2304 x 1296,2560 x 1440,2688 x 1520
Brennviddeområde:	8 - 32 mm
Strømforbruk (vanlig bruk):	12.4 W
Støttede videofunksjoner:	720p, 1080p
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	-30 - 60 °C
Oppbevaringstemperaturomåde (Celsius):	-30 - 60 °C
Innebygd kortleser:	Ja
Lukkerhastighet:	1/3 - 1/100000 s
nattsyn:	Ja
IK-kode:	IK10
Formfaktor:	Kuppel
Quality of Service (QoS) støtte:	Ja
CCD-sensorstørrelse:	1/1.8 "
Modell/Type:	IP-sikkerhetskamera
Kroppsmateriale:	Metall
Innebygd harddisk:	Nei
Panoreringsomfang:	0 - 355 °
DC-inngangskontakt:	Ja
Internasjonal beskyttelses (IP)-kode:	IP67
Flip og speil:	Ja
Bithastighetskontroll:	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Støttede Windows operativsystemer:	Ja
Minimumsbelysning:	0.002 lx
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Raskt Ethernet
Relativ luftfuktighet under drift (H-H):	0 - 95
Lyd-utgang kanaler:	1 kanaler
Støttede plasseringer/plasseringer som kan benyttes:	Inne & Ute
Montasjetype:	Tak/Vegg
Totale megapiksler:	4 MP
Maksimal størrelse på hukommelseskort:	256 GB
Normal fokuseringsrekkevidde:	2.5 - 6 m
Webbasert administrasjon:	Ja
Plugg inn og spill:	Ja
DC-ut, volt:	12
Region of Interest (ROI)-koding:	Ja
Bit-rate:	H.264: 32 Kbps–8192 Kbps, H.265: 19 Kbps– 8192 Kbps
Privacy maske:	Ja
Effektiv distanse for nattsyn:	80 m
Maksimal blenderåpning:	1.6
Panoreringskontroll:	Ja
Vippekontroll:	Ja
Stemmekodekser:	G.711a, G.711alaw, G.723, G.723.1, G.726, G.726-32
Videobasert bevegelsesdeteksjon:	Ja
Baklyskompensasjon (BLC):	Ja
Auto-fokus:	Ja
Alarminngang/-utgang:	Ja
Highlight Compensation (HLC):	Ja
Vinningskontrolltype (gain):	Automatisk/Manuell
Aktiv tuklealarm:	Ja
Mennesketellerfunksjon:	Ja
Streaming-metode:	Multicast, Unicast
Tåkesikker:	Ja
Kamelukkertype:	Elektronisk
Fast fokus:	Ja
Antall lysende LED:	3
Styringsprogramvare:	Smart PSS, DSS, DMSS
Justering av lukkerhastighet:	Automatisk/Manuell
Auto-flipp:	Ja
Analytisk videointelligens:	Ja
