8/16 ports Rack-mount

KVM Switch with OSD

EK EK-08RE -16RE

EK EK- RE(or08 - " rackmout PS/2 switches which a cost-effective solution for multiple16 19RE) is KVM is

servers / management. - are robust durable machines metal enclosure and canPCs EK 08RE and in

control up to 8 PS/2 computers using one PS/2 keyboard, monitor and PS/2 mouse.

Featuring a hot-plugging capability, - allows you disconnect from without powering downEK 08RE PCs

the whole rack servers. - with OSD (On Screen Display) provides more convenientof EK 08RE and

intuitive menu-driven operation for KVM switching.

With its password protection, - can prevent unauthorized users access. - canEK 08RE to EK 08RE be

maximized ports stacking 8 units. Flexible control control front- push buttons,up 49to by up to by panel

keyboard hotkeys OSD menu makes your PCs /servers management hassles-free. - offersand EK 08RE

an operation transparency that any professionals will come to appreciate.

Key Features:

•Rack-mount size (19") 8/16 ports KVM switch

•Supports High Video Resolution up to 1920 x 1440 with bandwidth 250MHz

•Supports Microsoft Intellimouse, Microsoft Optical Mouse, Microsoft Intellimouseexplorer, Logitech Net

Mouse…etc.

•Supports DOS, Win3.X, Win95/98/98SE/2000/ME/XP/Vista, WinNT, Netware, Unix, Linux.

•Hot Plug - Connect/Disconnect from PCs without powering down PCs

•PC selection via Push Buttons, Hotkeys (user definable) and OSD (On Screen Display Menu)

•Supports Auto Scan (Programmable) to monitor PCs

•Supports Password protection for advanced security

•Restores Keyboard status when switching PCs

•LED Display for easy status monitoring

•Buzz sound for switching confirmation

SETUP DIAGRAM

Model NO. / Type

PS/2 KVM PS/2 KVM

EK EK-08RE -16RE

Max PC Connecons 8 16

PC Side Connecon HD15M X 8 (VGA) HD15M X 16 (VGA)

Console Side Connecon HD 15F x 1 (VGA) / MD 6F x 2 (K & M)

PC Selecon Hot Keys / Push Buons / OSD

Console Cable 1 x 1.8 meter (Max transmission distance : 5meters)

PC to Switch Distance 10 meters

Frequency

Horizontal :30-180KHz

Vercal : 43-250Hz

Scan Intervals 5,10,15,20,25,30 Sec.

VGA Resoluon 1920 x 1440

Max. Bandwidth 250MHz

Operaon informaon Temperature : 0~50 C / Humidity : 0~90%, Non-Condensing°

Weight 1.1kg 2.32gk

Dimension 438 x 169 x 43mm 436.5 x 190 x 43mm 2.32gk

FEATURES AND TECHNICAL SPECIFICATIONS

Produkspesifikasjoner

Merke:	Edimax
Kategori:	Bryter
Modell:	EK-16RE
Vekt:	2320 g
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Kompatible operativsystemer:	DOS, Win3.X, Win95/98/98SE/2000/ME/XP/Vista, WinNT, Netware, Unix, Linux
Dimensjoner (B x D x H):	436.5 x 190 x 43 mm
Antall porter:	16
Antall datamaskiner:	16
Videobåndbredde:	250 Hz
Kabellengde:	10 m
Driftstemperatur (T-T):	0 - 50 °C
Relativ luftfuktighet under drift (H-H):	0 - 90
Video tilkoblingstype:	VGA
Tastatur tilkoblingstype:	PS/2
Mus tilkoblingstype:	PS/2
