GS-5208PLG

User Manual

11-2020 / v1.1

CONTENTS

Chapter 1 Product Information ............................................................. 3

1-1 Product Overview ................................................................................................................. 3

1-2 Features ................................................................................................................................. 3

1-3 External Component Description ......................................................................................... 4

1-3-1 Front Panel .................................................................................................................... 4

1-3-2 Rear Panel...................................................................................................................... 5

1-4 Package Contents .................................................................................................................. 5

1-5 Rack-mountable Installation ................................................................................................ 6

Chapter 2 Connect & Login ................................................................... 7

2-1 Switch to End Node ............................................................................................................... 7

2-2 Login ...................................................................................................................................... 8

Chapter 3 Switch Configuration ........................................................... 10

3-1 System ................................................................................................................................. 11

3-1-1 Device Name Setup ..................................................................................................... 12

3-2 Management ....................................................................................................................... 13

3-3 Port ...................................................................................................................................... 15

3-4 VLAN .................................................................................................................................... 16

3-4-1 IEEE 802.1Q VLAN ........................................................................................................ 16

3-5 Trunking ............................................................................................................................... 18

3-6 QoS....................................................................................................................................... 20

3-7 Broadcast Storm Control .................................................................................................... 22

3-8 Rate Limiting ....................................................................................................................... 23

3-9 Loop Detect/Prevent ........................................................................................................... 24

3-10 IGMP Snooping .................................................................................................................... 25

3-11 POE....................................................................................................................................... 26

3-12 Password ............................................................................................................................. 28

3-13 Logout .................................................................................................................................. 29

Chapter 1 Product Information

1-1 Product Overview

The Giga Ethernet POE Switch provides a seamless network connection, with integrated

1000Mbps Gigabit Ethernet, 100Mbps Fast Ethernet and 10Mbps Ethernet network

capabilities.

1-2 Features

 IEEE 802.3af/at PoE compliant.

 Eight Gigabit Ethernet ports.

 Up to 30W per port (total power budget: 160W) for powering PoE-enabled devices.

 Auto-detection of powered devices (PD) and power consumption levels.

 Auto fault-detection on over/under current & voltage.

 Access Control List (ACL) support.

 Switch capacity:20Gbps & Forwarding rate:14.88Mpps.

 IEEE 802.1Q-based VLAN for network segmentation to improve performance and

security.

 IEEE 802.1p QoS with 4 priority queues

 IGMP Snooping V1 / V2 / V3 support.

 4K MAC address table and jumbo frame support up to 9KB.

 19-inch 1U rack-mount brackets included.

Produkspesifikasjoner

Merke:	Edimax
Kategori:	Bryter
Modell:	GS-5208PLG
Vekt:	1700 g
Bredde:	184 mm
Dybde:	265 mm
Høyde:	44 mm
LED-indikatorer:	Activity, Link, Power, Status
Sertifisering:	FCC A, CE
Nettverksstandard:	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Virtuelle LAN-funksjoner:	Tagged VLAN
10G støtte:	Nei
Antall VLAN:	4094
Multicast-støtte:	Ja
Bufferstørrelse:	192 KB
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Jumbo rammer:	9200
Fiberoptisk kontakt:	SFP
Antall køer:	4
Produktfarge:	Sort
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 70 °C
Lagringsrelativ fuktighet:	5 - 90
Formfaktor:	1U
Quality of Service (QoS) støtte:	Ja
tilbakestillingsknapp:	Ja
Oppgraderbar fastvare:	Ja
Ethernet-kobberkabelteknologi:	10BASE-T, 100BASE-TX, 1000BASE-T
Relativ luftfuktighet under drift (H-H):	10 - 90
Rack-montering:	Ja
Monteringsbeslag inkludert:	Ja
Svitsjtype:	Håndtert
Webbasert administrasjon:	Ja
Antall Basic switching RJ-45 Ethernet-ports:	8
Basic switching RJ-45 Ethernet ports-type:	Gigabit Ethernet (10/100/1000)
Størrelse på adressetabell:	4000 oppføringer
Ruting/svitsjekapasitet:	20 Gbit/s
Strøm over Ethernet (PoE):	Ja
Power over Ethernet (PoE) effekt per port:	30 W
Antall Power over Ethernet plus (PoE+)-ports:	8
IGMP-snooping:	Ja
Jumbo Frames-støtte:	Ja
Total Power over Ethernet (PoE)-budsjett:	130 W
VLAN støtte:	Ja
Lagre-og-videresend:	Ja
Videresendingshastighet:	14.88 Mpps
SFP module antall spor:	2
Access Control List (ACL)/tilgangskontrolliste:	Ja
Kringkasting stormkontroll:	Ja
Loop beskyttelse:	Ja
Ethernet-fiberkabelteknologi:	1000BASE-X
Antall multifrekvensgrupper filtrert:	129
Pakke videresending rate (1 Gbps):	1488000 pps
Pakke videresending rate (100 Mbps):	148800 pps
Pakke videresending rate (10 Mbps):	14880 pps
