Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included
in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved
File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\4010110_01086.doc
Erstelldatum / create date: 12.06.2006 17:44:00 Aktualisiert / up dated: 05.12.2007
Features:
- Pressure reducer (1)
- Pressure switch (2)
- Air intake filter (3)
- 1 gauge for non-regulating vessel pressure
- 1 gauge for regulating the working pressure
- Drain valve (4)
- Back pressure valve
- Safety valve
- Undercarriage with push strap
- Main cable with earthed plug
- CE-vessel certicate to norm EN 286
- 10 years warranty for the vessel
Compressor
Art.-No.: 40.101.10
Euro 2500-2
Bar-Code: 4006825401769
Sales Unit:1 pc
As special accessory available:
5 pcs. Air pressure Set Profi
Art.-No.: 41.327.20
Bar-Code: 4006825410020
Air pressure hose 10 m
Art.-No.: 41.381.00
Bar-Code: 4006825410082
The
Euro
2500
-
2
the ideal equipment for DIY an convinced through huge air capacity at a high pressure. The mobile
and oil-lubricated 1-cylinder compressor with direct coupled engine is suitable for nearly all compressed air
application. Especially for coating, clamp, spraying and blow up of balls and wheels. Furthermore, the advantage of
the 50 l air pressure tank is that during its operation air must be refilled more rarely.
Technical data:
- Air intake capacity: 256 l/min
- Vessel size: 50 l
- Speed: 2850 min
-1
- Mains: 230 V ~ 50 Hz
- Motor power: 1,8 kW (2,5 PS)
- Operating pressure max: 8 bar
- Weight: 41 kg
- Packing dimension: 775 x 330x 715 mm
1
3
2
4
