Side 1/60
RLYM-1
WRLYM-1
Available with / Disponible avec / Verkrijgbaar met / Verfügbar mit
230V Mains Powered Fire & CO Alarm Relay Unit
Unité de relais alimentée sur secteur 230V pour détection incendie et CO
230 V netgevoed relais voor rook-, hitte- en koolmonoxidemelders
230V Netzbetriebene Rauch-, Hitze- CO-Melder-Relaiseinheit
EN: PLEASE READ THIS GUIDE IN FULL BEFORE USING YOUR RELAY!
FR : VEUILLEZ LIRE INTÉGRALEMENT CE GUIDE AVANT D’UTILISER VOTRE RELAIS !
NL: LEES DEZE GIDS VOLLEDIG DOOR ALVORENS HET RELAIS IN GEBRUIK TE NEMEN!
DE: LESEN SIE BITTE DIESE ANLEITUNG VOR DER VERWENDUNG DES RELAIS VOLLSTÄNDIG DURCH!
RLYM-1 /
WRLYM-1
Hereby, FireAngel Safety Technology Limited, declares that this relay unit is in compliance with the essential requirements and
other relevant provisions of
Directive 2014/53/EU.
The declaration of conformity may be consulted at http://spru.es/WRLYM-1
FireAngel Safety Technology Limited déclare ici que cette unité de relais est conforme aux exigences essentielles et autres
dispositions applicables de la
Directive 2014/53/EU.
La déclaration de conformité est consultable sur http://spru.es/WRLYM-1
FireAngel Safety Technology Limited verklaart hierbij dat dit relais aan de essentiële eisen en andere relevante bepalingen voldoet
van
Richtlijn 2014/53/EU.
De conformiteitsverklaring kan worden geraadpleegd op http://spru.es/WRLYM-1
FireAngel Safety Technology Limited erklärt hiermit, dass diese Relaiseinheit den wesentlichen Anforderungen und anderen
relevanten Bestimmungen der
Richtlinie 2014/53/EU
entspricht. Die Konformitätserklärung nden Sie unter http://spru.es/
WRLYM-1
Only/Uniquement/Alleen/Nur WRLYM-1:
Independently tested to RF standard / Testé indépendamment selon les normes
RF / Onafhankelijk getest op RF-norm / Unabhängig getestet nach RF-Standard:
Frequency 868.3 MHz
EN 300 220-2 V3.1.1
EN 301 489-3 V1.6.1
EN 301 489-1 V1.9.2
3
EN
INTRODUCTION . . . . . . . . . . . . . . . . . . . 4
INSTALLATION EXAMPLES . . . . . . . . . . . . . 4
INSTALLATION . . . . . . . . . . . . . . . . . . . . 5
HARDWIRE INTERCONNECT (RLYM-1 ONLY) . . . 7
WIRELESS INTERLINK (WRLYM-1 ONLY) . . . . . . 8
WIRELESS SET-UP . . . . . . . . . . . . . . . . . 9
MIXED SYSTEM COMPATABILITY. . . . . . . . . 10
BATTERY BACK-UP . . . . . . . . . . . . . . . . 11
12V DC EXTERNAL POWER SOURCE
(WRLYM-1 ONLY) . . . . . . . . . . . . . . . . . 11
CONTENTS
Note: This user manual is also available in large text and other formats. Please e-mail
technicalsupport@reangeltech.com for further
information.
The original English version of the manual, from which this translation was taken, has been independently approved. In case of
discrepancy with translated parts, FireAngel Safety Technology Limited conrms that the English guide is true and correct.
230 V AC 50 - 60 Hz mains powered. Non replaceable 6V battery back-up. The normal operating temperature range for this
product is 0 °C to 40 °C. WARNING: Wiring should be installed by a qualied electrician in accordance with BS7671. We advise
you to follow the new harmonized cable colour coding as specied in BS7671.
Please ensure to leave this manual with the end user as contains important information regarding the maintenance of this
product. Please keep this user manual in a safe place.
12–24V EXTERNAL TRIGGER INPUT
(RLYM-1 and WRLYM-1) . . . . . . . . . . . . . . 12
CONTACTS AND OPERATION. . . . . . . . . . . 12
DIPSWITCH RELAY OPERATION (ACTIVATION). . 13
TESTING . . . . . . . . . . . . . . . . . . . . . . 13
ALARM . . . . . . . . . . . . . . . . . . . . . . . 14
TROUBLESHOOTING . . . . . . . . . . . . . . . 14
TECHNICAL SPECIFICATION . . . . . . . . . . . 15
DISPOSAL . . . . . . . . . . . . . . . . . . . . . 15
WARRANTY . . . . . . . . . . . . . . . . . . . . 15
