Side 1/4

Six outlet power conditioners with standard surge protection, EMI/RFI ﬁltration,

heavy duty steel construction, and 15 ft. power cords.

The SS-6B-Pro includes the Furman EVS (Extreme Voltage Shutdown) technology that

will disconnect the power conditioner from the AC mains to protect your connected

equipment as well as itself. The high shutdown is set at 140 Vac +/- 5% while the

low shutdown is set at 95 Vac +/- 5%.

POWER CONDITIONERS

PRO PLUGS

SS-6 / SS-6B / SS-6B-Pro / PlugLOCK / ACX-25

POWER DISTRIBUTION UNITS

SS-6

SS-6B SS-6B-Pro

PlugLOCK

Lock your plugs and

transformers in place,

ensuring you never

get disconnected from

your power source

ACX-25

Discreet, 25 ft. power

cord provides ultimate

durability and longevity

Whether it’s on-stage or in the studio, Furman

Pro Plugs give you the protection you need.

With surge protection, noise ﬁltration, and

diagnostic lighting, you can trust Furman Pro

Plugs for reliable, clean, and protected power.

Our products have saved billions of dollar’s

worth of equipment from power problems, and

our innovative technologies maximize system

performance.

WHAT

ARE YOU

PLUGGING

INTO?

Rev A, 04/2018

15A Rating

15A Rating 15A Rating

Diagnostic Lights

Diagnostic Lights Diagnostic Lights

6 Outlets

6 Outlets 6 Outlets

5 Outlets

3 Outlets

Standard Level

Surge Protection

Standard Level

Surge Protection

Standard Level

Surge Protection

Standard Level

RFI/EMI Filtration

Standard Level

RFI/EMI Filtration

Standard Level

RFI/EMI Filtration

EVS Voltage

Protection

POWER CONDITIONERS SS-6 SS-6B SS-6B-Pro

AC Protection Technology

Standard spike and surge protection

UL VPR:400V, UL Nominal

Standard spike and surge protection

UL VPR:400V, UL Nominal

Standard spike and surge protection

UL VPR:400V, UL Nominal

Signal Pulse Energy Dissipation

540 Joules 540 Joules 540 Joules

Filtration Technology

Standard level RFI/EMI ﬁltration

Filter: -20dB Min, 100kHz – 1MHz

Standard level RFI/EMI ﬁltration

Filter: -20dB Min, 100kHz – 1MHz

Standard level RFI/EMI ﬁltration

Filter: -20dB Min, 100kHz – 1MHz

Under-Voltage Shutoff

— — 95VAC +/- 5%

Over-Voltage Shutoff

— — 140VAC +/- 5%

Dimensions

2.5”W x 1.5”D x 14.5”H 3.5”W x 1.5”D x 9.5”H 3.5”W x 1.5”D x 9.5”H

Weight

2.52lbs 2.64lbs 2.64lbs

AC Power Cord

15ft. captive cord (14AWG) 15ft. captive cord (14AWG) 15ft. captive cord (14AWG)

Outlets

6 6 6

Line Voltage

120V 120V 120V

Current Rating

15 amps 15 amps 15 amps

Safety Listing

cULus cULus cULus

Warranty

1 year 1 year 1 year

POWER DISTRIBUTION UNITS PlugLOCK ACX-25

Dimensions

2.3”W x 2.5”D x 12.6”H —

Weight

2.125lbs 3lbs

AC Power Cord

5ft. captive cord (14AWG) 25ft. (14AWG)

Outlets

5 3

Line Voltage

120V 120V

Current Rating

15 amps 15 amps

Safety Listing

cCSAus cULus

Warranty

1 year 1 year

is a registered trademark of Nortek Security & Control. | 1800 South McDowell Blvd, Petaluma, CA 94954, USA | Rev A, 04/2018

PRO PLUGS SS-6 / SS-6B / SS-6B-Pro / PlugLOCK / ACX-25

To ﬁnd your local Furman

Dealer or Regional Sales

Representative, please visit:

www.FurmanPower.com

Product Video

#1 in Power Protection for Over 40 Years

Produkspesifikasjoner

Merke:	Furman
Kategori:	grenuttak
Modell:	SS-6B-Pro
Vekt:	1197 g
Bredde:	88.9 mm
Dybde:	38.1 mm
Høyde:	241.3 mm
LED-indikatorer:	Ja
Antall per boks:	1 stykker
Overspenningsindikator:	Ja
Kabellengde:	4.5 m
Produktfarge:	Sort
Av/på-bryter:	Ja
Antall AC outlets:	6 AC-utganger
AC-utgangstyper:	NEMA 6–15P
Nominell innputspenning:	120 V
Strømstøt energivurdering:	540 J
EMI/RFI-lydfiltrering:	-20 dB
Nominell strømoutput:	15 A
