Side 1/2

Technology GmbH

www.icybox.de

RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany

Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.icybox.de

Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.

Free-standing monitor stand for one

monitor up to 27" (68 cm)

Key features

• Free-standing monitor stand, for a monitor up to 27" (68 cm)

• Removable VESA

mount allows easy installation

• 10 height settings for optimal monitor viewing

• Cable management elegantly directs all cables downward

• Non-slip silicone pads on base protect against scratches and scrapes

• Heavy-duty stand for stability and up to 6 kg load capacity

Article no.

EAN code

Brand

Colour

Material

Maximum size of monitor

Number of monitors

Max. weight of monitor

Mounting

VESA

compatible

Swivel (Hinge) - VESA

Tilt (Hinge) - VESA

Rotate (Pivot) - VESA

Height adjustment VESA

Max arm height

60876

4250078172093

ICY BOX

Black

Plastic, steel

17" – 27"

6 kg

Free-standing

Yes, 75x75, 100x100

+30° – -30°

+60° – -20°

+180° – -180°

360 - 500 mm

540 mm

Technical data

Packing content

IB-MS113B-T, allen wrench, set of screws, quick installation guide

ICY BOX

IB-MS113B-T

Technology GmbH

www.icybox.de

Free-standing monitor stand for one monitor up to 27" (68 cm)

At eye level

The monitor stand is perfectly designed for a screen diagonal of up to 27". With a maximum monitor arm height

of 540 mm, it is ideal for adjusting your monitor to your eye level. The Quick Release VESA

plate ensures a

quick installation of the monitor.

No scratches

Thanks to the foam padding on the underside of the stand, your desk remains protected from scratches. In ad-

dition, the foam padding ensures that the stand does not shift, especially when you want to adjust the monitor

or reposition it on the desk.

Solid construction

Due to its long-lasting metal construction, the IB-MS113B-T is very stable. The heavy stand has the advantage

that you do not have to mount an additional bracket on the tabletop or even drill holes in the desk or worktop.

Accordingly, the monitor stand can be set up quickly.

Logistical data

Packing unit:

Total weight:

Gross weight (with packing):

Net weight:

Dimension/carton:

Dimension (with packing):

Dimension of article:

Country of origin:

RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany

Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.icybox.de

Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.

4 pcs./carton

17.90 kg/carton

4,38 kg

3.90 kg

370x450x170 mm

220x360x80 mm

200x320x540 mm

China

ICY BOX IB-MS113B-T

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	veggfeste
Modell:	IB-MS113B-T
Vekt:	3900 g
Bredde:	320 mm
Dybde:	200 mm
Høyde:	540 mm
Pakkevekt:	4380 g
Antall per pakke:	1 stykker
Antall skjermer som støttes:	1
Maksimal skjermstørrelse:	27 "
Minimum skjermstørrelse:	17 "
Høydejusteringsområde:	360 - 540 mm
Høydejustering:	Ja
Produktfarge:	Sort
Vippevinkelområde:	-20 - 60 °
Pakkedybde:	220 mm
Pakkehøyde:	80 mm
Pakkebredde:	360 mm
Pakketype:	Boks
Kroppsmateriale:	Plastic, Steel
Svingvinkel:	-180 - 180 °
Montering:	Frittstående
Vippjustering:	Ja
Dreietapp/dreiemekanisme:	-30 - 30 °
Montasjetype:	Bord
Maksimalvekt (kapasitet):	6 kg
Masterkassens (ytterkassens) bruttovekt:	17900 g
Masterkassens (ytterkassens) lengde:	450 mm
Produkter per masterkasse (ytterkasse):	4 stykker
Masterkassens (ytterkassens) bredde:	370 mm
Masterkassens (ytterkassens) høyde:	170 mm
Monteringsgrensesnitt, kompatibilitet (min):	- mm
Monteringsgrensesnitt, kompatibilitet (maks):	- mm
Kan justeres i høyden:	Manuell
Enkel installering:	Ja
Forlengelsesarm (maks.):	540 mm
