Declaration of Conformity

Manufacturer: InFocus Corporation 13190 SW 68th Parkway, Portland, Oregon 97223-8368

USA

We declare under our sole responsibility that this projector

conforms to the following

directives and norms:

EMC Directive 2004/108/EC

EMC: EN 55022

EN 55024

EN 61000-3-2

EN 61000-3-3

Low Voltage Directive 2006/95/EC

Safety: IEC 60950-1: 2005

Trademarks

Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple

Computer, Inc. IBM is a trademark or registered trademark of International Business

Machines, Inc. Microsoft, PowerPoint, and Windows are trademarks or registered trademarks

of Microsoft Corporation. Adobe and Acrobat are trademarks or registered trademarks of

Adobe Systems Incorporated. DLP® and the DLP logo are registered trademarks of Texas

Instruments and BrilliantColor™ is a trademark of Texas Instruments. InFocus, In Focus, and

INFOCUS (stylized) are either registered trademarks or trademarks of InFocus Corporation in

the United States and other countries.

FCC Warning

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the

limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instruction, may cause harmful interference to radio communications.

However, there is no guarantee that interference will

not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an out

let on a circuit different from that to which the receiver is

connected.

--Consult the dealer or an experienced r

adio/TV technician for help.

Changes or modifications not expressly approved by

InFocus Corporation may void authority

to operate the equipment.

EN 55022 Warning

This is a Class B product. In a domestic environment it may cause radio interference, in which

case the user may be required to take adequate measures. The typical use is in a conference

room, meeting room or auditorium.

Canada

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est con

forme à la norme NMB-003 du Canada.

Agency Approvals

UL, cUL

Other specific Country Approvals may apply

. Please see product certification label.

This document applies to regulator

y models IN1110 and IN1112.

Input ratings: 100-240Vac, 2.3-0.9A, 50-60Hz

InFocus reserves the right to alter pr

oduct offerings and specifications at any time without

notice.

Table of Contents

Introduction 3

Positioning the projector 5

Connecting a computer source 6

VESA connection 6

HDMI connection 6

Power connection 6

Optional computer connections 6

Displaying an image 7

Adjusting the image 8

Video device connections 9

Composite video connection 9

HDMI 1.3 connection 9

S-video connection 9

VESA connection 9

Component video connection 9

Shutting down the projector 10

Troubleshooting your setup 10

Using the remote control 18

Using the audio 19

Using the keypad buttons 20

Optimizing computer images 21

Presentation features 21

Optimizing video images 22

Customizing the projector 22

Using the menus 23

Basic menu 24

Advanced > Image menu 25

Advanced > Setup menu 26

Advanced > Status/Service menu 30

Maintenance 31

Cleaning the lens 31

Using the security lock 31

Replacing the projection lamp 32

Important Operating Considerations for Safety

• Place the projector in a horizontal position no

greater

than 15 degrees off axis.

• Locate the projector in a well-ventilated area without any obstructions to

intake or exhaust vents. Do

not place the projector on a tablecloth or other soft

covering that may block the vents.

• Locate the projector at least 4' (1.2 m) away from any h

eating or cooling vents.

• Only genuine InFocus lamps are tested for use in this projector.

InFocus is not

liable for the performance, safety or certification of any other lamps. The use

of other lamps violates the projector warranty and voids all certification marks

on this projector.

• Use only the power cord provided. A sur

ge-pro

tected power strip is

recommended.

• Refer to this guide for proper startup and shutdown procedures.

• Hg – Lamp contains mercury

. Manage in accordance with local disposal laws.

See www.lamprecycle.org.

• In the unlikely event of a lamp rupture, particles

may exit through the p

rojector

side vents. When the projector is turned on, keep people, food, and drinks out

of the "keep out" area under and around the projector, as indicated by the "X"

areas below.

2’ / 0.6 m

3’ / 1 m

’ /1.5m

’

/2.4m

Follow these instructions to help ensure image quality and lamp life over the life of

the projector. Failure to follow these instructions may affect the warranty. For

complete details of the warranty, see the Warranty Booklet.

Produkspesifikasjoner

Merke:	InFocus
Kategori:	videoprosjektor
Modell:	IN1110a
Produkttype:	Standard stråleprojektor
Innebygd skjerm:	Nei
Vekt:	1200 g
Bredde:	213 mm
Dybde:	181 mm
Høyde:	65 mm
Støynivå:	33 dB
Strømkilde:	AC
Bluetooth:	Nei
Plassering:	Tak
Intern lagringskapasitet:	2 GB
Wi-Fi:	Nei
USB-kontakttype:	Mini-USB B, USB Type-A
Pakkevekt:	3400 g
Antall farger:	16.78 million farger
Antall USB 2.0-porter:	2
Antall HDMI-porter:	1
DVI-port:	Nei
Fokus:	Manuell
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Strømforbruk (maks.):	220 W
Sertifisering:	FCC, cULus, WEEE, C-Tick, S-Mark, NOM, CE, Gost, CECP/CCC, CE/TUV-GS, KC Mark, SASO, PSB, SABS
Full HD:	Nei
3D:	Ja
Forhåndsinnstilte moduser:	Beige wall, Blackboard, Bright, Cinema, Custom, Presentation, Whiteboard
Forhåndsinstallert programvare:	EZ WiFi
Horisontal synkronisering (min):	31.4 kHz
Vertikal synkronisering (min):	23.5 kHz
Kontrastforhold:	2600:1
AC-inngangsspenning:	90 - 264 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	2100 ANSI lumen
Projektoroppløsning:	XGA (1024x768)
Støttede bildeformater:	BMP, JPG
Støttede lydformater:	AAC, ADPCM, MP1, MP2, MP3, OGG, PCM, WAV, WMA
Produktfarge:	Sort
Pakkedybde:	290 mm
Pakkehøyde:	395 mm
Pakkebredde:	185 mm
Naturlig sideforhold:	4:3
Støttede grafikkoppløsninger:	1920 x 1200 (WUXGA)
Analogt signalformatsystem:	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Kabler inkludert:	AC, USB, VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	22 - 242 "
Projeksjonsavstand:	1.2 - 12 m
Hjørnesteinsrettelse, vertikal:	± 30 °
Støynivå (økonomisk funksjon):	29 dB
Zoomfunksjon:	Ja
Brennviddeområde:	- mm
Zoom-type:	Manuell
Lyskildens tjenestetid:	3000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	180 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Antall VGA (D-Sub)-porter:	1
Strøminngang/AC (strøm) inn:	Ja
Driftstemperatur (T-T):	5 - 35 °C
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Minimum prosessor:	Dual Core Intel Core i 1.6 GHz / Dual Core Intel Core i 1.4 GHz
Driftshøyde:	0 - 2286 m
forskyvning:	15
OSD-språk:	PER, ARA, CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
PC-lydinngang:	Ja
Lampestrøm (økonomisk modus):	132 W
PC-lyd ut:	Ja
Støttede Windows operativsystemer:	Ja
Ethernet/bredbåndsforbindelse:	Nei
Komposittvideo inn/sammensatt video inn:	1
Lydutgang (venstre/høyre):	1
RMS-rangert strøm/utgangseffekt:	1 W
Horisontal synkronisering (maks):	91.1 kHz
Vertikal synkronisering (maks):	85 kHz
Markedsplassering:	Bærbar
Lampens effekt:	165 W
Lyskildens tjenestetid (økonomisk modus):	4000 timer
Projeksjonsfaktor:	1.95 - 2.15:1
Bæretaske:	Ja
Kabellåsport:	Ja
Kabellåstype:	Kensington
Zoom-forhold:	1.1:1
Videoformat som støttes:	H.263, H.264, M-JPEG, MPEG1, MPEG4, RV, WMV, XVID
Støttede forhold:	4:3, 5:4, 16:9, 16:10
Støttede Mac operativsystemer:	Ja
Passordbeskyttelsestype:	Bruker
Dokumentformater som støttes:	DOC, DOCX, PDF, PPT, PPTX, XLS, XLX
Projektor lysstyrke (økonomisk funksjon):	1550 ANSI lumen
