Usage Notice ...................................2

Safety Information ...............................2

Precautions .........................................3

Eye Safety Warnings ..........................5

Product Features ................................5

Introduction ...................................... 6

Package Overview ..............................6

Product Overview ...............................7

Front View ............................................ 7

Rear View ............................................ 8

Control Panel ....................................... 9

Input/Output Connections .................. 10

Remote Control .................................. 11

Installation .....................................12

Connecting the Projector ..................12

Connect to Computer/Notebook ........ 12

Connect to Video Sources ................. 13

Powering the Projector On / Off ........14

Powering On the Projector ................. 14

Powering off the projector .................. 15

Warning Indicator ............................... 15

Adjusting the Projected Image ..........16

Adjusting the Projector’s Height ........ 16

Adjusting the Projector’s Focus /

Zoom .................................................. 17

Adjusting Projection Image Size ........ 18

User Controls ................................24

Control Panel & Remote Control ......24

Control Panel ..................................... 24

Remote Control Battery Installation ... 25

Remote Control .................................. 26

On-screen Display Menus ................30

How to operate .................................. 30

Menu Tree .......................................... 31

IMAGE ............................................... 34

IMAGE | Advanced ............................36

IMAGE | Advanced | Signal .............. 38

DISPLAY ............................................ 39

DISPLAY | 3D ................................... 41

SETUP ............................................... 42

SETUP | Audio Settings ..................... 44

SETUP | Network ............................... 45

SETUP | Advanced ............................ 46

OPTIONS ........................................... 47

OPTIONS | Advanced ........................ 49

OPTIONS | Lamp Settings ................. 51

OPTIONS | Optional Filter Settings ... 52

Appendices .................................... 53

Network Control ................................53

Network Menu .................................... 53

Troubleshooting ................................61

Replacing the Lamp ..........................67

Installing and Cleaning the Optional

Dust Filter .........................................69

Compatibility Modes .........................71

Computer/Video/HDMI/Mac

Compatibility ...................................... 71

RS232 Commands and Protocol

Function List .....................................73

RS232 Pin Assignments .................... 73

RS232 Protocol Function List ............ 74

Ceiling Mount Installation ..................79

Regulation & Safety Notices .............81

FCC Notice ........................................ 81

Notice: Shielded cables ..................... 81

Caution .............................................. 81

Operation Conditions ......................... 82

Notice: Canadian users ..................... 82

Remarque à l’intention des

utilisateurs canadiens ........................ 82

Declaration of Conformity for EU

countries ............................................ 82

Table of Contents

English

Usage Notice

Safety Information

The lightning ash with arrow head within an equilateral triangle is

intended to alert the user to the presence of uninsulated “dangerous

voltage” within the product’s enclosure that may be of sufcient

magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH

VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE

CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

Important Safety Instruction

1. Do not block any ventilation openings. To ensure reliable operation of the

projector and to protect from overheating, it is recommended to install the

projector in a location that does not block ventilation. As an example, do

not place the projector on a crowded coffee table, sofa, bed, etc. Do not

put the projector in an enclosure such as a book case or a cabinet that

restricts air ow.

2. Do not use the projector near water or moisture. To reduce the risk of re

and/or electric shock, do not expose the projector to rain or moisture.

3. Do not install near heat sources such as radiators, heaters, stoves or any

other apparatus such as ampliers that emit heat.

4. Clean only with dry cloth.

5. Only use attachments/accessories specied by the manufacturer.

6. Do not let objects or liquids enter the projector. They may touch

dangerous voltage points and short out parts that could result in re or

electric shock.

7. See projector enclosure for safety related markings.

8. The unit should only be repaired by appropriate service personnel.

English

Usage Notice

Precautions

Please follow all warnings, precautions and

maintenance as recommended in this user’s

guide.

▀■ Warning- Do not look into the projector’s lens when the lamp is

on. The bright light may hurt and damage your eyes.

▀■ Warning- To reduce the risk of re or electric shock, do not

expose this projector to rain or moisture.

▀■ Warning- Please do not open or disassemble the projector as

this may cause electric shock.

▀■ Warning- When replacing the lamp, please allow the unit to

cool down. Follow instructions as described on pages

67-68.

▀■ Warning- This projector detects lamp life. Please be sure

to change the lamp when a warning message is

displayed.

▀■ Warning- When switching the projector off, please ensure

the cooling cycle has been completed before

disconnecting power. Allow 90 seconds for the

projector to cool down.

▀■ Warning- Not all projectors come with a lens cap. For your

safety, if the projector is equipped with a lens cap

please ensure to remove it before you turn on the

projector.

When the lamp

reaches the end

of its life, the

projector will

not turn back on

until the lamp

module has

been replaced.

To replace the

lamp, follow the

procedures listed

under “Replacing

the Lamp”

section on pages

67-68.

Produkspesifikasjoner

Merke:	InFocus
Kategori:	videoprosjektor
Modell:	IN138HDST
Produkttype:	Projektor med kort stråle
Innebygd skjerm:	Nei
Vekt:	3200 g
Bredde:	312.4 mm
Dybde:	236.2 mm
Høyde:	124.5 mm
Støynivå:	21 dB
Strømkilde:	AC
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Batterikapasitet:	- mAh
Anbefalt alder (min):	- år
Bluetooth:	Nei
Plassering:	Desktop, Ceiling, Tripod
Prosessorfrekvens:	- GHz
Intern lagringskapasitet:	- GB
Wi-Fi:	Nei
Pakkevekt:	4500 g
Antall farger:	1.073 milliarder farger
Antall HDMI-porter:	3
DVI-port:	Nei
Smart TV:	Nei
Fokus:	Manuell
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Passordbeskyttelse:	Ja
Strømforbruk (maks.):	330 W
Sertifisering:	UL, c-UL, FCC, CE, CCC+CECP, KCC, NOM, PCT/CU/EAC, PSB, SABS, CB, Nemco/GS, KC
Full HD:	Ja
Innebygd mikrofon:	Nei
Internminne:	- GB
Bluetooth Low Energy (BLE):	Nei
3D:	Ja
HDMI-versjon:	1.4a
Sammensatt synkronisering:	Nei
Luftfilter:	Nei
Miracast:	Nei
Nettleser:	Nei
Støyreduksjon:	Nei
Antall per pakke:	- stykker
Fargedybde:	- bit
On Screen Display (OSD):	Ja
Audio Return Channel (ARC):	Nei
Programmeringsperiode:	- dager
Hotellmodus:	Nei
Batterier kreves:	Ja
Skjermspeiling:	Nei
Bluetooth-rekkevidde:	- m
Strømforbruk (nettverk standby):	0.5 W
Horisontal synkronisering (min):	31.5 kHz
Vertikal synkronisering (min):	56 kHz
HID-støtte:	Nei
Ensartethet:	80
12V trigger:	Ja
Logisk kanalnummer (LCN):	Nei
Justerbar fargetemperatur:	Ja
Kontrastforhold:	28500:1
HDBaseT-port:	Nei
Produkter per pall:	- stykker
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Batteritype:	AA
Produkter per pallelag:	- stykker
Produkter per pall (Storbritannia):	- stykker
Skjermoppløsning:	- piksler
Øyebeskyttelse:	Nei
TruMotion-teknologi:	Nei
(cdm) Hjulstørrelse:	- cm
Produkter per pallelag (Storbritannia):	- stykker
Pallebredde (Storbritannia):	- mm
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	4000 ANSI lumen
Projektoroppløsning:	1080p (1920x1080)
Kabellengde:	- m
Støttede bildeformater:	BMP, JPEG XR, JPG, PNG
Støttede lydformater:	AAC, MP3, WAV, WMA
Produktfarge:	Sort
Pakkedybde:	337.8 mm
Pakkehøyde:	195.6 mm
Pakkebredde:	398.8 mm
Skjermdiagonal:	- "
Naturlig sideforhold:	16:9
Batteriliv (maks.):	- timer
AC-adapter utgangsspenning:	- V
Rekomandert kjønn:	Alle kjønn
Støttede grafikkoppløsninger:	800 x 600 (SVGA),854 x 480 (WVGA),1024 x 600,1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 800 (WXGA),1440 x 900 (WXGA+),1600 x 1200 (UXGA),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA)
Separat H/V-synkronisering:	Ja
Analogt signalformatsystem:	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Kabler inkludert:	AC, HDMI, IR
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	45 - 300 "
Projeksjonsavstand:	0.4 - 3.4 m
Hjørnesteinsrettelse, horisontal:	-20 - 20 °
Brennviddeområde:	- mm
RS-232-port:	1
Lyskildens tjenestetid:	5000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	300 W
Slår seg automatisk av:	Ja
Støttede videofunksjoner:	480i, 480p, 576i, 720p, 1080i, 1080p
Antall VGA (D-Sub)-porter:	1
HDMI-kontakttype:	Full-size
Lydinngang (V/H) inn:	1
Mikrofon, linje-inn-støpsel:	Nei
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 60 °C
Fjernkontroll medfølger:	Ja
Fjernkontrolltype:	IR
AUX-inngang:	Nei
Antall deler:	- stykker
Kroppsmateriale:	Plast
Elektronisk programguide (EPG):	Nei
Innebygd prosessor:	Nei
Driftshøyde:	0 - 3048 m
forskyvning:	116
Tekst-TV-funksjon:	Nei
DC-inngangskontakt:	Nei
Lampetype:	UHP
Strøm:	- A
OSD-språk:	ARA, CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FRE, HIN, HUN, IND, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, VIE
PC-lydinngang:	Ja
Lampestrøm (økonomisk modus):	170 W
PC-lyd ut:	Ja
Ethernet LAN dataoverføringshastigheter:	10, 100 Mbit/s
Ethernet/bredbåndsforbindelse:	Nei
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	1
Lysstyrke for skjerm:	- cd/m²
Komposittvideo inn/sammensatt video inn:	1
Lydutgang (venstre/høyre):	1
Antall OSD språk:	27
RMS-rangert strøm/utgangseffekt:	10 W
Batterier medfølger:	Nei
Horisontal synkronisering (maks):	97.6 kHz
Vertikal synkronisering (maks):	120 kHz
Markedsplassering:	Hjemmekino
Lampens effekt:	245 W
Lyskildens tjenestetid (økonomisk modus):	10000 timer
Forbruk (økonomimodus):	220 W
Fjern (IR)-utgang:	1
Mobil HD-lenke (MHL):	Nei
PC inn (D-Sub):	Ja
Monteringsbeslag inkludert:	Nei
Bæretaske:	Nei
Innebygd TV-mottaker:	Nei
Kabellåsport:	Ja
Stativ medfølger:	Nei
Kabellåstype:	Kensington
AC-adapter bunt:	Nei
Maksimal størrelse på hukommelseskort:	- GB
Videoformat som støttes:	3GP, AVI, MOV, MP4, MPEG, MPG, RM, RMVB
Støttede forhold:	4:3, 16:10, 16:9
Strømforbruk, strømsparing:	- W
Oppladingstid:	- timer
Montering nødvendig:	Nei
Fakturaenhet:	Ja
Bestillbar enhet:	Ja
3D-briller medfølger:	Nei
Utjevner/frekvenskorrigerer:	Nei
Vanlig grensesnitt pluss (CI+):	Nei
Dvalefunksjon:	Ja
4K ultra HD oppskalering:	Nei
HDR (High Dynamic Range) støttes:	Nei
HbbTV:	Nei
Bærekraftsamsvar:	Ja
Masterkassens (ytterkassens) bruttovekt:	- g
Masterkassens (ytterkassens) lengde:	- mm
Produkter per masterkasse (ytterkasse):	- stykker
Masterkassens (ytterkassens) bredde:	- mm
Masterkassens (ytterkassens) høyde:	- mm
Minimum ordreantall:	- stykker
S/PDIF-utport:	Nei
Pallens bruttolengde:	- mm
Pallens bruttobredde:	- mm
Pallens bruttohøyde:	- mm
Pallens bruttovekt:	- g
Consumer Electronics Control (CEC)-støtte:	Nei
Matrisetype:	DMD
Projeksjonsmoduser:	Ceiling, Front, Rear
Pallelengde (Storbritannia):	- mm
Pallehøyde (Storbritannia):	- mm
Pallevekt (Storbritannia):	- g
Projektor lysstyrke (økonomisk funksjon):	3200 ANSI lumen
Manualspråk (ISO 639-format):	Multi
Sync-on-green (SOG):	Nei
