Side 1/66

Regulatory models: F5500, F5530

5500

010-0715-01

IN5502, IN5504, IN5532, IN5534 User’s Guide

Declaration of Conformity

Manufacturer: InFocus Corporation, 13190 SW 68th Parkway, Portland,

Oregon 97223-8368 USA

We declare under our sole responsibility that this projector conforms to the

following directives and norms:

EMC Directive 2004/108/EC

EuP Directive 2005/32/EC

EMC: EN 55022

EN 55024

EN 61000-3-2

EN 61000-3-3

Low Voltage Directive 2006/95/EC

Safety: IEC 60950-1:2005, MOD

Trademarks

DisplayLink is a trademark of DisplayLink Corporation.

Apple, Macintosh, and PowerBook are trademarks or registered trademarks

of Apple Computer, Inc. IBM is a trademark or registered trademark of

International Business Machines, Inc. Microsoft, PowerPoint, and Windows

are trademarks or registered trademarks of Microsoft Corporation. Adobe

and Acrobat are trademarks or registered trademarks of Adobe Systems

Incorporated. DLP® and the DLP logo are registered trademarks of Texas

Instruments and BrilliantColor™ is a trademark of Texas Instruments.

InFocus, In Focus, and INFOCUS (stylized) are either registered trademarks

or trademarks of InFocus Corporation in the United States and other

countries.

FCC Warning

This device complies with part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference

when the equipment is operated in a commercial environment. This

equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. Operation of the

equipment in a residential area is likely to cause harmful interference in

which case the user will be required to correct the interference at his own

expense.

Changes or modifications not expressly approved by InFocus Corporation

may void authority to operate the equipment.

EN 55022 Warning

This is a Class A product. In a domestic environment it may cause radio

interference, in which case the user may be required to take adequate

measures. The typical use is in a conference room, meeting room or

auditorium.

Canada

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du

Canada.

Agency Approvals

UL, cUL

Other specific Country Approvals may apply. Please see product

certification label.

This document applies to regulatory models F5500, F5530.

Input ratings:

For Single Lamp models (F5500) - AC100-240V 5.0-2.0A, 50-60Hz

For Dual Lamp models (F5530) - AC 100-240V, 9.5-3.5A, 50-60Hz

InFocus reserves the right to alter product offerings and specifications at

any time without notice.

Table of Contents

Introduction 5

Positioning the projector 7

Ceiling Mount 8

Cable management 8

Connecting power 9

Connecting a computer source 9

Optional computer connections 10

Displaying an image 11

Adjusting the image 12

Connecting a video device 13

Video device connections 13

Shutting down the projector 15

Troubleshooting your setup 15

Using the remote control 23

Using the audio 24

Using the keypad buttons 25

Optimizing computer images 25

Presentation features 25

Optimizing video images 26

Customizing the projector 26

Dynamic Messaging 26

Using the menus 27

Basic Picture menu 28

Advanced Picture menu 29

Setup menu 30

Status and Service menu 33

Help 33

Using Network Functions 34

Using LitePort 38

Maintenance 41

Cleaning the lens 42

Replacing the projection lamp (single lamp) 43

Replacing the projection lamp (dual lamp) 44

Using the security lock 47

Appendix 48

Projected Image Size 48

Optional Lenses 49

SplitScreen Compatibility 53

RS-232 commands 45

Index 64

Produkspesifikasjoner

Merke:	InFocus
Kategori:	videoprosjektor
Modell:	IN5504
Vekt:	20000 g
Støynivå:	29 dB
Antall USB 2.0-porter:	2
Antall HDMI-porter:	2
Antall innebygde høyttalere:	2
Hodetelefonutganger:	1
Dimensjoner (B x D x H):	431.8 x 670 x 240 mm
Kontrastforhold:	2000:1
Projektorens lysstyrke:	5000 ANSI lumen
Projektoroppløsning:	WUXGA (1920x1200)
Analogt signalformatsystem:	NTSC, PAL, SECAM
Visningsteknologi:	DLP
Horisontalt frekvensområde:	15 - 100 kHz
Lyskildens tjenestetid:	2000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	500 W
Komponentvideo (YPbPr/YCbCr) inn:	1
Antall S-Video-innganger:	1
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	10 W
Lampens effekt:	330 W
Lyskildens tjenestetid (økonomisk modus):	2500 timer
Størrelseforhold:	16:10
Vertikal scanningsratio:	50 - 85 Hz
