Side 1/28
IX AMPLIFIER
IX500.4
English Version
Versión Español
Amplificador del la Serie IX.4
Deutsche Version
Stereoverstärker der IX.4-Serie
Version Francaise
Amplificateur de série IX.4
LIVIN’ LOUD
2010 IX 500.4 RevB.indd 12010 IX 500.4 RevB.indd 1 11/12/2009 2:16:32 PM11/12/2009 2:16:32 PM
2
IX AMPLIFIERS
IX.1-SERIES AMPLIFIERS Owner’s Manual
IX500.4
INSTALLATION
Mounting: Choose a structurally sound location to mount your KICKER amplifi er. Make sure there are no items
behind the area where the screws will be driven. Choose a location that allows at least 4” (10cm) of open
ventilation for the amplifi er. If possible, mount the amplifi er in the climate-controlled passenger compartment.
Drill four holes using a 7/64” (3mm) bit and use the supplied #8 screws to mount the amplifi er. Use the IXSM
mounting bracket (sold separately) to stack IX amplifi ers of different sizes.
PERFORMANCE
Authorized KICKER Dealer:
Purchase Date:
Serial Number:
Model: IX500.4
RMS Power
@ 14.4V, 4Ω stereo, 1% THD+N
@ 14.4V, 2Ω stereo, 1% THD+N
@ 14.4V, 4Ω mono, 1% THD+N
75W x 4
125W x 4
250W x 2
Length 11-3/8” (288mm)
Height 2-3/16” (55mm)
Width 7-7/8” (200mm)
Frequency Response ± 1dB 20Hz–20kHz
Signal-to-noise Ratio 98dB, A-weighted, re: rated power
Input Sensitivity Low Level: 125mV–5V
High Level: 250mV–10V
Electronic Crossover Selectable HI/LO/OFF, Variable lo-pass 50–200Hz,
12dB/octave
Bass Boost Variable 0–18dB @ 40Hz
Maximum Effi ciency (2Ω) >80%
Pro Tip: To get the best performance from your new KICKER Amplifi er and extend the warranty by 1 year, use
genuine KICKER accessories and wiring.
IXSM
sold separately
2010 IX 500.4 RevB.indd 22010 IX 500.4 RevB.indd 2 11/12/2009 2:16:38 PM11/12/2009 2:16:38 PM
