Side 1/32
KXA400.2 | KXA1200.2
KXA400.4
Manual del Propietario | Español
AMPLIFICADOR DEL LA SERIE KX.2
Benutzerhandbuch | Deutsch
STEREOVERSTÄRKER DER KX.2-SERIE
Manuel d’utilisation | Française
AMPLIFICATEUR DE SÉRIE KX.2
KX
AMPLIFIERS
Owner’s Manual
2017 KXA Stereo Amps Rev H.indd 12017 KXA Stereo Amps Rev H.indd 1 7/13/2017 12:15:05 PM7/13/2017 12:15:05 PM
2
KX.2-SERIES AMPLIFIERS
OWNER’S MANUAL
INSTALLATION
Mounting: Choose a structurally sound location to mount your KICKER amplifi er. Make sure there are no
items behind the area where the screws will be driven. Choose a location that allows at least 4” (10cm)
of open ventilation for the amplifi er. If possible, mount the amplifi er in the climate-controlled passenger
compartment. Drill four holes using a 7/64” (3mm) bit and use the supplied #8 screws to mount the
amplifi er.
Wiring: Disconnect the vehicle’s battery to avoid an electrical short. Then, connect the ground wire to the
amplifi er. Make the ground wire short, 24” (60cm) or less, and connect it to a paint-and-corrosion-free,
solid, metal area of the vehicle’s chassis. Adding an additional ground wire of this same gauge (or larger)
between the battery’s negative post and the vehicle chassis is recommended.
PERFORMANCE
MODEL: KXA400.2 | KXA1200.2 | KXA400.4
IMPORTANT SAFETY WARNING
PROLONGED CONTINUOUS OPERATION OF AN AMPLIFIER, SPEAKER, OR SUBWOOFER
IN A DISTORTED, CLIPPED OR OVER-POWERED MANNER CAN CAUSE YOUR AUDIO
SYSTEM TO OVERHEAT, POSSIBLY CATCHING FIRE AND RESULTING IN SERIOUS
DAMAGE TO YOUR COMPONENTS AND/OR VEHICLE. AMPLIFIERS REQUIRE UP TO 4
INCHES (10CM) OPEN VENTILATION. SUBWOOFERS SHOULD BE MOUNTED WITH AT
LEAST 1 INCH (2.5CM) CLEARANCE BETWEEN THE FRONT OF THE SPEAKER AND ANY
SURFACE.
Model: KXA400.2 KXA400.4 KXA1200.2
RMS Power
@ 14.4V, 4 stereo, ≤ 1% THD+N
@ 14.4V, 2 stereo, ≤ 1% THD+N
@ 14.4V, 4Ω mono, ≤ 1% THD+N
100 x 2
200 x 2
400 x 1
50 x 4
100 x 4
200 x 2
300 x 2
600 x 2
N/A
Length [in, cm] 9-9/16, 24.4 11-3/16, 28.4 11-3/16, 28.4
Specifi cations common to all models:
Height [in, cm] 2-1/8, 5.5
Width [in, cm] 8-5/16, 21
Frequency Response [Hz] 10Hz–20kHz
Signal-to-Noise Ratio [dB] 95dB
Input Sensitivity 250mV–10V
Selectable Electronic Crossover Off; Variable HP, 10–500Hz; Variable LP, 40–500Hz;
400Hz–5,000Hz with 10X Switch (bandpass capable);
Slope: 24dB/octave"
KickEQ™ Bass Boost 0–18dB @ 40Hz
2017 KXA Stereo Amps Rev H.indd 22017 KXA Stereo Amps Rev H.indd 2 7/13/2017 12:15:14 PM7/13/2017 12:15:14 PM
3
Install a fuse within 18” (45cm) of the battery and in-line with the power cable connected to your amplifi er.
If you ever need to remove the amplifi er from the vehicle after it has been installed, the ground wire should
be the last wire disconnected from the amplifi er--just the opposite as when you installed it.
POWER WIRING
source unit
high-level speaker
outputs
to amplifi er
shield
+
–
core conductor
KICKER KISL (optional)
from source unit high-
level speaker outputs
OR
to amplifi er
Model External Fuse
(sold separately)
Power/Ground Wire KICKER Wiring Kit
KXA400.2 1 x 60 Ampere 8 Gauge PK8, CK8
KXA400.4 1 x 100 Ampere 4 Gauge PK4, CK4
KXA1200.2 1 x 150 Ampere 4 Gauge PK4, CK4
12V
RADIO
DETECT
OFF/ON
battery
external fuse
remote turn-on
(see page 6)
bare-metal chassis ground
bare-metal
chassis ground
≤18”
(45cm)
≤24”
(60cm)
audio inputs
The KX amplifi er’s RCA inputs will receive either high or low level signals from your car stereo’s source
unit. A high-level signal can be run from the source unit’s speaker outputs to the stereo RCA input on the
end panel of the amplifi er using the KICKER KISL as shown. Alternatively, the signal can be delivered to
the amplifi er using the low-level RCA outputs on the source unit. Keep the audio signal cable away from
factory wiring harnesses and other power wiring. If you need to cross this wiring, cross it at a 90 degree
angle.
2017 KXA Stereo Amps Rev H.indd 32017 KXA Stereo Amps Rev H.indd 3 7/13/2017 12:15:15 PM7/13/2017 12:15:15 PM
