Side 1/4

The Konftel 300IP is a conference phone for IP telephony.

A manual containing details of features and settings and an

administrator’s manual for advanced conﬁgurations are both

available on our website: www.konftel.com/300ip.

Please refer to the enclosed “Konftel 300IP Installation Guide” for

connection and installation instructions.

SD memory card port

It is possible to record a call in progress

and use the Konftel 300IP as a dictaphone.

Press the button to start and stop

recording.

Recordings can be accessed via the menu.

LEDs

Flashing blue Incoming call

Steady blue light Call in progress

Flashing red Hold, microphone and

speaker turned off

Steady red light Mute, microphone turned off

Konftel 300IP Quick Reference Guide

ENGLISH

Display symbols

In call mode

Line free

Line connected

Line on hold

Line (called party) busy

Line put on hold by other

party

Recording call

Secure connection

Before account name

Telephone not registered

Telephone registered

NAVIGATE IN MENUS AND MAKE SETTINGS

Line selection

DESCRIPTION

The Konftel 300IP

menu contains the

following options:

PROFILES

PHONE BOOK

EXT. PHONE BOOK

CONF GUIDE

RECORDING

SETTINGS

SYSTEM

STATUS



Press .



Select the option you want from the menu using the arrow keys.

Press OK to conﬁrm.



Cancel the setting or go back one level in the menu by pressing



Quit the menu by pressing again.

 Note that after you have made changes to a setting, you must

press OK to activate the setting.

The simplest way to make settings and edit contacts is using a

PC and the Konftel 300IP web interface.

Please refer to the manual for details.

Alphanumerical buttons

Hold down a button for 2 seconds

to open the phonebook

Yes/conﬁrm choice

Conference

Automatic dialling of confer-

ence groups

One press of this button will

always connect all parties to a

conference call

Answer/connect calls and Flash

During a call: Press to call a

new person

Hang up/end call

Settings

Navigation in menus

Display of call list

No/end/back

Start/stop

recording

Increase volume

Decrease volume

Mute, the caller

cannot hear you

Hold, puts a call

on hold

Navigation in menus

Display of call list

BESKRIVELSE • TILKOBLING • LINJEVELGEREN

ANSWERING AND MAKING

CALLS



Press to answer an incoming call.



Dial the number and press to make a

call.



Press an arrow key to open a call list

containing previously dialled numbers.

Call using .



Press and hold an alphanumeric button

for two seconds to call a contact in the

phonebook.

DURING A CALL



Adjust the speaker volume using the

keys and .



Press to turn off the microphone.



Press to put the call on hold.

Both the microphone and the speaker are

turned off and the call is on hold.



Press the same button again to recon-

nect the call.

CALLS

MAKING MULTI-PARTY CALLS



Press during the call to get a new

dialling tone.

Calls in progress are put on hold.



Dial the new number.



Press the (Conference) key to con-

nect the calls.

THE CONFERENCE GUIDE

You can create groups of up to six people via

> CONF. GUIDE > ADD GROUP.

Making conference group calls



Press the (Conference) button and

choose a conference group. Press OK if

you want to see who is in the group and

to make the call.

The Konftel 300IP dials all the contacts in

the group.

The box in front of a person’s name ﬁlls as

soon as that person answers.

MULTI-PARTY CALLS

Produkspesifikasjoner

Merke:	Konftel
Kategori:	Telefon
Modell:	300IP
Produkttype:	IP-konferansetelefon
Innebygd skjerm:	Ja
Vekt:	1000 g
Bredde:	240 mm
Dybde:	240 mm
Høyde:	77 mm
Bruksanvisning:	Ja
Pakkevekt:	1520 g
Innebygde høyttalere:	Ja
Volumkontroll:	Digitalt
Sertifisering:	RoHS
Støyreduksjon:	Ja
Kablingsteknologi:	Ethernet 10/100 Base T
Nettverksstandard:	IEEE 802.3ab, IEEE 802.3af
Lydtrykknivå:	90 dB
Flash-minne:	2 MB
Elektromagnetisk kompatibilitet:	EN 301 489-3 V1.4.1 (2002-08), EN 301 489-1 V1.6.1 (2005-09), F CC Part 15 B class A, F CC Part 15 C, EN 300220-1:2000, EN 300220-2:2000
Sikkerhet:	EN 60950-1:2006, ANSI/UL 60950-1-2002, CAN/CSA-C22.2, N o. 60950-1-03
Mikrofonretningstype:	Retningsuavhengig
Dimensjoner (B x D x H):	240 x 240 x 77 mm
Produkter per pall:	72 stykker
AC-inngangsspenning:	100 - 240 V
Minnekortspor:	Ja
Skjermoppløsning:	128 x 64 piksler
Garantiperiode:	2 år
Anbefalt romstørrelse:	Middels store rom
Produktfarge:	Sort
Pakkedybde:	300 mm
Pakkehøyde:	115 mm
Pakkebredde:	270 mm
Skjermtype:	LCD
Minnekortenhet:	SD, SDHC
AC-adapter utgangsspenning:	13.5 V
Kontrolltype:	Knapper
Kabler inkludert:	LAN (RJ-45)
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 40 °C
Bærekraftsertifikater:	Low Voltage Directive (LVD), REACH, RoHS, WEEE
Quality of Service (QoS) støtte:	Ja
Mikrofonens opptaksrekkevidde:	4.5 m
DC-inngangskontakt:	Ja
Samsvar med industristandarder:	IEEE 802.3af
Samtale venter:	Ja
Ethernet LAN dataoverføringshastigheter:	10, 100 Mbit/s
Antall RJ45-porter:	1
Sikkerhetsalgoritmer:	SRTP
Ethernet-grensesnittype:	Raskt Ethernet
Krav til strømforsyning:	100 - 240 V AC/13.5 V DC
Relativ luftfuktighet under drift (H-H):	20 - 80
Display:	LCD
Kabellåsport:	Ja
Kabellåstype:	Kensington
AC-adapter bunt:	Ja
Strøm over Ethernet (PoE):	Ja
Guide for hurtiginstallering:	Ja
Mikrofondemping:	Ja
Skjermbelysning:	Ja
Ekkokansellering:	Ja
Utjevner/frekvenskorrigerer:	Ja
Produkter per masterkasse (ytterkasse):	6 stykker
Kompatibel med Mac:	Nei
Telefonlistekapasitet:	1000 oppføringer
Samtale på vent:	Ja
Trådløse forbindelser:	Nei
Frekvensrekkevidde:	200 - 7000 Hz
Egnet for romvolum opptil:	30 m²
Frekvens (MHz):	200 - 7000
Internettilkobling nødvendig:	Ja
Konferansesamtaler:	Ja
Utvidelsesmikrofoner støttes:	Ja
Samtalelagring:	Ja
