Side 1/4

SD memory card port

It is possible to record a call in progress and use the

Konftel 300 as a dictaphone.

Press the

REC

/C button to start and stop recording.

Recordings can be accessed via the menu.

LEDs

Flashing blue Incoming call

Steady blue light Call in progress

Flashing red Hold, microphone and

speaker turned off

Steady red light Mute, microphone turned off

Konftel 300W Quick Reference Guide

ENGLISH

The Konftel 300W is a bat tery-

driven wireless conference phone

that can be connected to DECT

systems, mobile phones or PCs. It

can be connected to a Konftel DECT

base station or any GAP-compatible

DECT system.

A user guide with detailed instruc-

tions about connectivity options and

features is available on our website:

www.konftel.com/300W.

Signal strength DECT

Date

Time

Battery charging

Fully charged

< 1 hr talk time

Display symbols Charging the battery

Charge the battery by

placing the Konftel 300W on

the charging stand or plug the

power cable into the Konftel

300W.

A fully-charged battery

provides up to 48 hours of talk

time. The Konftel 300W lets you

know when there is less than one

hour of talk time left.

NAVIGATE IN MENUS AND MAKE SETTINGS

Alphanumerical buttons

Hold down a button for 2 seconds

to open the phonebook

Increase volume

Decrease volume

Mute

HOLD

LINE MODE

Connectivity options

DESCRIPTION

MENU,

Settings menu

UP ARROW

Navigation in menus

Display of call list

No/end/back

Start/ stop recording

Yes/conrm choice

CONFERENCE

Automatic dialling of

conference groups

One press of this button

will always connect all

parties to a conference call

DOWN ARROW

Navigation in menus

Display of call list

Answer/connect calls and

Flash

During a call: Press to call

a new person

Hang up/end call

The Konftel 300W

menu contains the

following options:

PHONE BOOK

SETTINGS

CONF GUIDE

RECORDING

STATUS



Press MENU.



Select the option you want from the menu using the arrow keys.

Press OK to conrm.



Cancel the setting or go back one level in the menu by pressing



Quit the menu by pressing MENU again.

 Note that after you have made changes to a setting, you must

press OK to activate the setting.

GETTING STARTED

USING A COMPUTER



Connect the Konftel 300W to a compu-

ter using the USB cable provided.



Select Konftel 300W USB Audio as the

sound unit in the computer’s settings.



Press the LINE MODE key. Select USB

and press OK to conrm.

Making VoIP calls



Press to activate the microphone in

the Konftel 300W.



Connect the call to the computer using,

for example, web conference software or

Skype

USING A MOBILE PHONE



Connect a mobile phone using an acces-

sory cable.



Press the LINE MODE key. Select

MOBILE and press OK to conrm.

Making mobile calls



Press to activate the Konftel 300W.



Connect the call with the mobile phone.

BASE STATION REGISTRATION



Put the base station in registration mode.



Select MENU > SETTINGS > DECT >



Select a base (1–4).



Enter the base station’s PIN code.

 The default code is 0000 for the Konftel

DECT base station.

The conference telephone will now search for

a base station. The base station has to be in

registration mode. If registration was success-

ful, the word READY will appear in the display.

The conference phone is now ready to use

Mini USB port for

PC connection

Produkspesifikasjoner

Merke:	Konftel
Kategori:	Telefon
Modell:	300W
Vekt:	1000 g
Tilkobling:	RJ-11
LED-indikatorer:	Ja
Antall USB 2.0-porter:	1
Volumkontroll:	Digitalt
Sertifisering:	EN, ES, FCC
Sikkerhet:	IEC, EN, ANSI/UL, CAN/CSA
Taletid:	60 timer
Navigasjonstast:	Ja
Dimensjoner (B x D x H):	240 x 240 x 177 mm
Maksimal utendørs rekkevidde:	200 m
Skjermoppløsning:	128 x 64 piksler
Produktfarge:	Sort
Type strømforsyning:	AC/DC
Driftstemperatur (T-T):	5 - 40 °C
Modell/Type:	DECT telefon
DC-inngangskontakt:	Ja
Språkstøtte:	DEU, DUT, ENG, FIN, FRE, ITA, NOR, RUS, SWE, TUR
Høyttalertelefon:	Ja
Krav til strømforsyning:	100 - 240V AC/14V DC
Relativ luftfuktighet under drift (H-H):	20 - 80
Display:	LCD
Mikrofondemping:	Ja
Full tosidig:	Ja
Telefonlistekapasitet:	50 oppføringer
Samtale på vent:	Ja
Maksimal innendørs rekkevidde:	50 m
Trådløse forbindelser:	Ja
Standbytid:	270 timer
Frekvens (MHz):	200 - 3300Hz
Skjermstørrelse (HxV) (imperisk):	5 x 2.5 "
Konferansesamtaler:	Ja
Basevekt:	240 g
LED på baseenheten:	Ja
