KONFTEL.COM

Konftel 300Mx 4G

Answering and making calls



Press to answer an incoming call.



Dial the number and press to make

a call.



Press an arrow key to open a call list

containing previously dialled numbers.

Call using



Press and hold an alphanumeric button

for two seconds to call a contact in the

phonebook.

During a call



Adjust the speaker volume using the

keys

and .



Press to turn o the microphone.



Press to put the call on hold.

Both the microphone and the speaker are

turned o and the call is on hold.



Press the same button again to recon-

nect the call.

CALLS

 Note that dierent PBXs may require

dierent signals. If you experience

problems making multi-party calls:

Please refer to the manual for infor-

mation about how to make necessary

settings and to your tele phone admin-

istrator or service provider for speciﬁc

settings.

Adding a party to a call



Press the button during the call.

Calls in progress are put on hold and a

second dialling tone is heard.



Dial the second participant’s number,

press and wait for an answer.



Press the button and then 3 to

connect all the meeting participants or

to return to the previous call.

The conference guide

You can create groups of up to six people

via

> CONF. GUIDE > ADD GROUP.



Press the (Conference) button and

choose a conference group. Press OK

if you want to see who is in the group

and

to make the call.



Follow the instructions in the guide

and answer with OK or

Calls in progress are put on hold when the

next participant calls.



Press the (Conference) button to

connect all the meeting participants.

MULTI-PARTY CALLS

The Konftel 300Mx 4G is a battery-operated wireless conference phone

that can be connected to mobile networks (4G/3G/2G) or PCs (USB).

A user guide with detailed instructions about connectivity options and

features is available on our website konftel.com.

QUICK START GUIDE

910101091 Rev 1A

DESCRIPTION

Alphanumerical buttons

Hold down a button for 2 seconds to open the

phonebook

Increase volume

Decrease volume

Mute

Hold

Connectivity options

Settings

Navigation in menus

Display of call list

No/end/back

Start/stop recording

Yes/conﬁrm choice

Conference

Automatic dialling of

conference groups

One press of this button will

always connect all parties

to a conference call

Navigation in menus

Display of call list

Answer/connect calls

During a call: Press to

call a new person

End call

On/o

SD memory card port

It is possible to record a call in progress

and use the Konftel 300Mx 4G as a

dictaphone.

Press the

button to start and stop

recording.

Recordings can be accessed via the menu.

Charging the battery

Charge the battery by placing the Konftel

300Mx 4G on the charging stand or plug

the power cable into the Konftel 300Mx

4G.

A fully-charged battery provides up to 30

hours of talk time. The Konftel 300Mx 4G

lets you know when there is less than one

hour of talk time left.

LEDs

Flashing blue Incoming call

Steady blue light Call in progress

Flashing red Hold, microphone and

speaker turned o

Steady red light Mute, microphone

turned o

Signal strength

Network type

Date and time

Operator

Battery charging

Unread messages

Fully charged

< 1 hr talk time

No battery

Connected to mains

Display symbols

GETTING STARTED

Initial use



Open the battery cover and insert the

SIM card as illustrated.



Insert the battery as shown in the

picture.



Enter the SIM card’s PIN code and

conﬁrm with OK.



Place the conference phone in the

middle of the table.

 Place the conference phone at least

20 cm from the users.

Connection to a PC



Connect the Konftel 300Mx 4G to a

computer using the USB cable provid-

ed.



Check that Konftel 300Mx 4G USB

Audio is selected as the sound unit in

the computer’s settings.

When connected to a PC, the Konftel

300Mx 4G functions as a conference

unit for VoIP calls, which means that

speakers and microphones are activated,

as is advanced sound management in

OmniSound

Bridge connection

As default, the sound via the mobile

network and USB is bridge-connected. It is

possible to turn o the bridging if you do

not want any sound from the computer to

be heard during mobile calls.



Press the button.



Conﬁrm with OK or cancel with .

Navigate in menus and make

settings

The Konftel 300Mx 4G menu contains the

following options:

CALL LIST PHONE BOOK

CONF GUIDE RECORDING

MESSAGES SETTINGS

STATUS



Press .



Select the option you want from the

menu using the arrow keys. Press OK

to conﬁrm.



Cancel the setting or go back one level

in the menu by pressing



Quit the menu by pressing again.

 Note that after you have made changes

to a setting, you must press OK to

activate the setting.

Unlock

Push SIM

card down

SIM card

(under battery)

Lock

Produkspesifikasjoner

Merke:	Konftel
Kategori:	Telefon
Modell:	300Mx
Vekt:	220 g
Inngangsspenning:	100 - 240 V
Utgangsstrøm:	14 V
Dimensjoner (B x D x H):	180 x 165 x 77 mm
Minnekortenhet:	SD, SDHC
Driftstemperatur (T-T):	5 - 40 °C
Harmonisert system (HS)-kode:	85258900
Frekvensrekkevidde:	200 - 7000 Hz
