INTERNAL USE ONLY: PN 24216
Lowell strives to provide accurate information while reserving the right to change specications and/or improve manufacturing methods without prior notication.
©2023 Lowell Manufacturing Co., 100 Integram Dr., Pacic MO 63069, USA / tel. 800.325.9660 / tel. 636-257-3400 / www.lowellmfg.com
Spec 1108
Model ACS-1510-RPC | Rev. 12.20.23 | pg. 1/3
POWER RATING: 120VAC 60Hz 15A
CHASSIS: 30” x 2” x 2” steel chassis with black powder epoxy finish
TERMINATION: Detachable six-ft. IEC cord with NEMA 5-15P plug
RECEPTACLES: Total of ten NEMA 5-15R receptacles (five duplex). One duplex is un-
switched (always on when supplied with power). Four duplexes are switched (controlled by
a remote switch or sequencer through the RPC terminal).
UNIVERSAL MOUNTING BRACKETS: The universal brackets allow for power strip instal-
lation in a variety of applications with receptacles facing front, center or rear. Brackets are
engineered with multiple mounting points and include two types of hardware to facilitate
easy installation in a rack with adjustable or fixed rails, to a wall, or under a desk/counter.
The brackets can be mounted so they are exposed for easy access or concealed beneath
the power strip for an aesthetically cleaner installation.
CERTIFICATION: ETL Listed in U.S./Canada
ORIGIN: Assembled in the U.S.A. with global components.
INSTALLATION
Use the universal mounting brackets to install the power strip near the equipment. Use
low-voltage cable to connect the RPC terminal to a remote switch or sequencer (required).
The corded power strip with ten 15A receptacles (ve duplex) and remote power control
function (RPC) can be combined with a variety of remote switches or sequencers to provide
a low-voltage method of turning specic equipment on and off from a remote location. The
ability to safely control AC power distribution without directly accessing equipment adds con-
venience, while minimizing the potential for unauthorized system modications.
ACS Series Model No.
ACS-1510-RPC
AC Power Strip w/Remote Power Control
FEATURES
Certied
US Steel
S
t
r
o
n
g
e
r
.
G
r
e
e
n
e
r
.
B
e
t
t
e
r
.
Assembled
In USA
with Global
Components
A&E SPECIFICATIONS
The ETL Listed power strip with low-voltage remote power control shall be Lowell model
ACS-1510-RPC, which shall have a power rating of 120VAC 60Hz 15A with circuit breaker
protection. The chassis shall be steel with black powder epoxy finish, measuring 30” x 2”
x 2”. It shall feature one unswitched and four switched NEMA 5-15R duplex receptacles.
The four switched duplexes shall be controlled by an external power switch or sequencer
(ordered separately) that is connected to the power strip’s remote power control terminal.
The power strip shall be made in the U.S.A. with global components. It shall terminate with
a detachable 6 ft. IEC cord with NEMA 5-15P plug, and include universal mounting brackets
with hardware to mount to a rack, wall or desk.
RPC terminal
connects to a
remote switch
or sequencer.
Four
duplexes are
controlled by a
remote switch
or sequencer
connected to
the RPC terminal.
One duplex
is unswitched
(always on).
Detachable
power cord
Mounting brackets
Note: An external
power switch or se-
quencer is required
(order separately,
pg. 2).
