Lowell strives to provide accurate information while reserving the right to change specications and/or improve manufacturing methods without prior notication.
©2021 Lowell Manufacturing Co., 100 Integram Dr., Pacic MO 63069 / tel. 800.325.9660 / www.lowellmfg.com
Spec 2169
Model ACS-1524 Rev. 05-05-21 | pg. 1/2
INTERNAL USE ONLY: PN 24220
Power strip with 24 NEMA 15A receptacles in a low prole chassis includes
surge suppression with LED status indicator.
FEATURES:
• Power Rating: 120VAC, 60Hz, 15A
• Chassis: 60" x 1.625" x 1.375" steel chassis with black powder epoxy
finish
• Termination: 12-ft. attached (non-removable) power cord with NEMA 5-15P
molded plug
• Receptacles: Total of 24 single NEMA 5-15R receptacles, spaced to allow
room for some power supplies.
• Surge Suppession: Common mode transient voltage surge suppression
(UL 1449-3 Listed) with 15A circuit breaker:
– LED indicator: Lit when protection is active
– Maximum surge current: 6500A (L-G, L-N, N-G)
– Maximum surge voltage: 6000V
– Suppressed voltage rating: 400V
– Energy dissipation: 450 Joules (8 x 20us waveform)
– Lines protected: L-G, L-N, N-G
– Response time: Less than one (1) nanosecond
– Noise ltering: EMI / RFI
• Mounting Hardware: Mounting clips and screws provided for vertical
installation in a rack that has adjustable or xed rails. Includes cable ties to
secure power supplies when the strip is mounted vertically.
• Certication: UL Listed
• Origin: China
• A&E Specications: The UL Listed power strip shall be Lowell model ACS-
1524, which shall have a power rating of 120VAC, 60Hz, 15A and include
a circuit breaker. It shall feature 24 NEMA 5-15R receptacles with space to
accommodate some power supplies. It shall include common mode transient
voltage surge suppression with LED indicator that is lit when protection is
active. The power strip shall have a suppressed voltage rating of 400V with
maximum surge voltage of 6000V and maximum surge current of 6500A. It
shall be terminated with an attached 12-foot cord and molded plug. It shall
include a mounting clip, screw, and cable ties.
AC Power Strip w/Surge Suppression: ACS-1524
Attached power cord
with plug
Receptacles
are spaced to
accept some
power supplies
15A circuit breaker
LED indicator
is lit when
protection is
active
Mounting hardware
Produkspesifikasjoner
| Merke: | Lowell |
| Kategori: | Ikke kategorisert |
| Modell: | ACS-1524 |
