Lowell strives to provide accurate information while reserving the right to change specications and/or improve manufacturing methods without prior notication.
©2021 Lowell Manufacturing Co., 100 Integram Dr., Pacic MO 63069 / tel. 800.325.9660 / www.lowellmfg.com
Spec 1728
Model ACS-2012 Rev. 05-05-21 | pg. 1/3
INTERNAL USE ONLY: PN 24222
Power strip features a total of twelve 15A and 20A NEMA receptacles in a low
prole chassis. It includes surge suppression with LED status indicator.
FEATURES:
• Power Rating: 120VAC, 60Hz, 20A
• Chassis: 32" x 1.625" x 1.375" steel chassis with black powder epoxy
finish
• Termination: 12-ft. attached (non-removable) power cord with NEMA 5-20P
molded plug
• Receptacles: (12 total)
– Eight (8) single NEMA 5-15R receptacles
– Four (4) single NEMA 5-20R receptacles
• Surge Suppession: Common mode transient voltage surge suppression
(UL 1449-3 Listed) with 20A circuit breaker:
– LED indicator: Llit when protection is active
– Maximum surge current: 6500A (L-G, L-N, N-G)
– Maximum surge voltage: 6000V
– Suppressed voltage rating: 400V
– Energy dissipation: 450 Joules (8 x 20us waveform)
– Lines protected: L-G, L-N, N-G
– Response time: Less than one (1) nanosecond
– Noise ltering: EMI / RFI
• Mounting Hardware: Clips and screws are provided for vertical installation
in a rack that has adjustable or xed rails. Includes cable ties to secure
power supplies when the strip is mounted vertically.
• Certication: UL Listed
• Origin: China
• A&E Specications: The UL Listed power strip shall be Lowell model ACS-
2012, whhich shall have a power rating of 120VAC, 60Hz, 20A and include a
circuit breaker. It shall feature twelve NEMA receptacles (eight 15A and four
20A). It shall include common mode transient voltage surge suppression
with an LED indicator that is lit when protection is active. The power strip
shall have a suppressed voltage rating of 400V with maximum surge voltage
of 6000V and maximum surge current of 6500A. It shall be terminated with
an attached 12-foot cord and molded plug. The power strip shall include a
mounting clip, screw, and cable ties.
AC Power Strip w/Surge Suppression: ACS-2012
Attached power cord
with plug
Receptacles
are spaced to
accept some
power supplies
20A circuit breaker
LED indicator
is lit when
protection is
active
Mounting hardware
