Side 1/8

APPLICATIONS

METRA. The World’s best kits.

™

metraonline.com1-800-221-0932

REV. 12/3/2013 INST95-5026

CAUTION: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE: Refer to the instructions included with the

aftermarket radio.

INSTALLATION INSTRUCTIONS FOR PART 95-5026

• DoubleDINradioprovision

•A)DoubleDINradiohousing•B)DoubleDINbrackets•C)Rearsupportbracket

KIT FEATURES

KIT COMPONENTS

WIRING & ANTENNA CONNECTIONS(soldseparately)

WiringHarness:

•70-5520-Fordharness2003-up

•70-5521-Fordamplifiedharness2003-up

•70-1771-Fordharness1998-up

AntennaAdapter:

•Notrequired

•Phillipsscrewdriver•Socketwrench

TOOLS REQUIRED

Ford/Lincoln/Mercury 2001-2006

95-5026

See application list inside

B C

Dash Disassembly

-FordMustang2001-2004................................................................................... 2

-FordExpedition(without NAV) 2003-2006.............................................................. 3

-FordExplorer2002-2005.................................................................................... 3

-LincolnNavigator(with NAV, THX amp) 2003-2006................................................. 4

-LincolnNavigator 2003-2006........................................................... 4(without NAV)

-LincolnAviator2003-2005...............................................................................4-5

-MercuryMountaineer2005................................................................................. 3

Kit Assembly

-DoubleDINradioprovision.................................................................................. 5

Table of Contents

Ford

Expedition ................ 2003-2006 (without NAV)

Explorer...................................... 2002-2005

Mustang..................................... 2001-2004

Lincoln

Aviator........................................ 2003-2005

Navigator (with NAV, THX amp)........ 2003-2006

Navigator ................. 2003-2006 (without NAV)

Mercury

Mountaineer............................... 2002-2005

Applications

1. Unclipandremoveshiftlevertrim

panel.(FigureA)

2. Unclipandremovetheentirepanel

surroundingtheradioandclimate

controlsincludingthevents.

3. Remove(2)9/32”screwssecuring

radio.(FigureB)

Continue to kit assembly

Ford Mustang 2001-2004

(Figure B)

(Figure A)

Dash Disassembly 95-502695-5026

Dash Disassembly 95-5026

1. Remove(2)9/32”screwsfrom

aboveinstrumentcluster.

(FigureA)

2. Unclipandremoveentirepanel

surroundingradio,climatecontrols,

andinstrumentcluster.(FigureB)

3. Remove(2)9/32”screws

securingradio.

Continue to kit assembly

Ford Expedition 2003-2006(withoutNAV)

1. Unclipandremoveentirepanel

surroundingradioincludingclimate

controlsandvents.(FigureA)

2. Remove(2)9/32”screwssecuring

radio.(FigureB)

Continue to kit assembly

Ford Explorer/Mercury Mounaineer

2002-2005

(Figure B)

(Figure A)

(Figure B)

(Figure A)
