Side 1/8
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2017 METRA ELECTRONICS CORPORATION REV. 10/17/17 INST99-7819
INSTALLATION INSTRUCTIONS
99-7819
KIT FEATURES
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Radio replacement pocket assembly
• Textured to match the factory finish
KIT COMPONENTS
• A) Radio trim panel • B) Radio replacement pocket assembly • C) Pocket • D) Radio brackets • E) Climate control brackets
• F) (10) #8 x 3/8” Phillips screws
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Socket wrench
TABLE OF CONTENTS
Dash Disassembly ...............................................2-3
Kit Preparation .......................................................4
Kit Assembly
–ISO DIN radio provision with pocket ..................4
–ISO DDIN radio provision .....................................5
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: 70-1721
Antenna Adapter: 40-HD10
A B DC E
F
Honda Pilot (with factory navigation) 2006-2008
1.800.221.0932
|
MetraOnline.com
2
1. Remove (2) Philips screws from under
the instrument cluster and remove the
trim. (Figure A)
2. Unclip and remove the trim panel
between the instrument cluster and the
NAV screen trim panel. (Figure A)
3. Unclip and remove the NAV screen trim
panel. (Figure B)
4. Remove (4) screws and remove the NAV
screen. (Figure C)
5. Remove (4) screws and remove the NAV
screen bracket. (Figure D)
Continued on next page
(Figure B)
(Figure D)
(Figure A) (Figure C)
DASH DISASSEMBLY
