120 95-5817 Supplemental Instructions
for Double-DIN Receiver Applications
120 95-5817I
Revision 04/05/11
*120955817I*
Permanent modifications will be necessary in order
to allow a Double-DIN receiver to fit into the dash of
vehicles that use the 120 95-5817 installation kit.
Removal of dash material is required. Once
modifications are made, the factory unit may not
properly fit if reinstalled.
Notes:
Do not remove too much material. It is better to
remove portions and measure or test fit as you go.
Test fit using the receiver only. The side brackets
should not be in place. If the receiver is fully
snapped into place, it cannot be removed without
the dash panel being removed.
1. Using a file or rotary tool, carefully remove
portions from the top and bottom rim of the dash
opening as shown.
2. Once a proper fit is achieved, complete
receiver installation following instructions supplied
with the 120 95-5817 installation kit.
Tools Required
File or
Rotary
Tool
Copyright 2011 Crutchfield Corporation
R
1-800-955-9094
TECHNICAL SUPPORT
Cut out these areas
Cut out these areas
Always be careful when cutting or drilling in a vehicle. WEAR
EYE PROTECTION. Be aware of things such as wiring,
windows, fuel lines and safety devices. Check drilling depth
and location to avoid damage to vehicle appearance.
CAUTION:
!
Produkspesifikasjoner
| Merke: | Metra |
| Kategori: | Bilsett |
| Modell: | 95-5817 |
