CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 2/21/18 INST99-5846B
INSTALLATION INSTRUCTIONS
99-5846B
KIT FEATURES
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Touchscreen display for climate and personalization features
• Integrated hazard button and passenger airbag light
• Radio can be mounted up top or at bottom
• Painted Matte Black
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 10mm & 9/32” Socket wrench
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................3
Kit Assembly
–ISO DIN radio provision with pocket ..................4
–ISO DDIN radio provision .....................................4
Axxess Interface Installation ............................ 5-13
WIRING & ANTENNA CONNECTIONS
Wiring Harness: Axxess interface built into touchscreen
Antenna Adapter: Included
Ford F-150 (with 4.2” screen) 2013-2014
KIT COMPONENTS
• A) Radio/Display trim panel with touchscreen display • B) Radio/Display sub-trim panel upper (a) • C) Radio/Display sub-trim panel lower (b)
• D) Radio brackets upper (a)
• E) Radio brackets lower (b) • F) Pocket • G) (4) Panel clips • H) (11) #6 x 3/8” Phillips pan-head screws
• I) (4) #8 x 3/8” Phillips truss-head screws • J) Touchscreen display assembly and wiring harness
• K) Antenna adapter (not shown)
A B C D
H I J
E F G
