INSTALLATION INSTRUCTIONS
99-7527S
Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 7/24/19 INST99-7527S
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
ISO DIN radio provision with pocket
DIN radio provision with pocket
ISO DDIN radio provision
Painted silver
Storage pocket included to replace the factory NAV screen
KIT COMPONENTS
• A) Radio Housing • B) ISO Brackets • C) ISO Trim Plate • D) Double DIN Brackets • E) Double DIN Trim Plate • F) Snap In Pocket
• G) NAV Screen Replacement Pocket
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Socket wrench
TABLE OF CONTENTS
Dash Disassembly ...............................................2-3
Kit Preparation .......................................................4
Kit Assembly
–DIN radio provision with pocket ........................5
–ISO DIN radio provision with pocket ..................6
–ISO DDIN radio provision .....................................7
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: 70-7903
Antenna Adapter: Not required
A CB
Mazda 5 (with factory NAV) 2006-2007
D E
F G
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
