CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 8/27/18 INST99-7617B
INSTALLATION INSTRUCTIONS
99-7617B
U.S. Patent # D757,707
KIT FEATURES
• ISO DIN radio provision with pocket
• Painted black
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Pocket • D) (4) #8 3/8” Phillips screws
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Assembly
–ISO DIN radio provision with pocket ..................3
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: 70-7552
Antenna Adapter: 40-NI12
Sterring wheel control interface: ASWC-1
A B C D
Nissan Altima 2016-2018
1.800.221.0932
|
MetraOnline.com
2
DASH DISASSEMBLY
1. Unclip the right side of the driver’s knee
bolster panel next to the center console
and let hang. (Figure A)
Note: There is no need to completely
remove the panel.
2. Unclip and remove the (2) silver side
trim panels from each side of the factory
radio. (Figure B)
3. Unclip and remove the trim panel below
the climate control panel.
4. Remove the (4) Phillips screws securing
the climate control panel and a/c vent
panel. (Figure C)
(Figure D)(Figure A)
(Figure E)(Figure B)
(Figure F)(Figure C)
5. Remove the climate control panel.
(Figure D)
6. Remove the a/c vent panel. (Figure E)
7. Remove the (4) Phillips screws securing
the radio, and then remove. (Figure F)
8. If equipped with automatic climate
controls, remove the (2) Phillips screws
securing the climate module under the
radio. This module will be reused in Kit
Assembly.
Continue to Kit Assembly
