INSTALLATION INSTRUCTIONS FOR PART 99-8222
99-8222/
99-8222BR
APPLICATIONS
Toyota Highlander
2008-2009
NON-NAV MODELS ONLY
KIT FEATURES
• DIN Radio Provision with Pocket
• ISO Mount Radio Provision with Pocket
• Double DIN Radio Provision
• Stacked ISO Mount Units Provision
• Painted to match factory dash:
99-8222 = Black, 99-8222BR = Brown
• A) Radio Housing • B) ISO Brackets • C) ISO Trim Plate • D) Double DIN Brackets
• E) Double DIN/Stacked ISO Trim Plate • F) Snap in Pocket • G) Radio Housing Brackets
KIT COMPONENTS
A
Small Flat Blade Screwdriver/ Panel Removal Tool
• Phillips Screwdriver • Socket Set
1-800-221-0932
© COPYRIGHT 2007-2009 METRA ELECTRONICS CORPORATION
www.metraonline.com
B
D
E
C
F
G
WIRING AND ANTENNA CONNECTIONS
(Sold Separately)
Harness:
• 70-1761 - Toyota interface 1987-up
• TYTO-01 - Toyota amplified interface
harness 2003-up
Antenna Adapter:
Not required
TOOLS REQUIRED:
Dash Disassembly
-
Toyota Highlander 2008 -2009. . . . . . . . . . . . . . . . . . . .
. . . . 1,2
Kit Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Kit
Assembly
- DIN Radio Provision with Pocket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
- ISO Mount Radio Provision with Pocket. . . . . . . . . . . . . . . . . . . . . . . . 5
- Double DIN Radio Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
- Stacked ISO Mount Units Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Final
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
TABLE OF CONTENTS
99-8222
*Note:
Refer also to the instructions included with the aftermarket radio.
K
NOWLEDGE IS
P
OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take
steps toward a better tomorrow.
