Side 1/16

METRA - The World’s best kits

metraonline.com

REV. 11/14/2017 INST99-7803G

Installation instructions for part 99-7803G

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

U.S. PATENT # D756,348

• ISO DIN radio provision with pocket

• ISO DDIN radio provision

• Retains all climate control systems including dual-zone

• Painted gray to match the factory finish

• A) Radio housing trim panel • B) Radio brackets • C) Pocket • D) Panel clip legs • E) (2) Panel clips

• F) (2) Speed clips • G) (2) #10 x ¾” Phillips screws • H) (4) #4 x 3/8” Phillips pan-head screws

• I) (8) #8 x 3/8”

Phillips truss-head screws • Wiring harness (not shown)

KIT FEATURES

KIT COMPONENTS

WIRING & ANTENNA CONNECTIONS (sold separately)

Wiring Harness: • Included with kit

Antenna Adapter: • Not Required

• Panel removal tool • Phillips screwdriver

TOOLS REQUIRED

Honda Accord 2003-2007

99-7803G

B C D E

F G H I

Dash Disassembly ................................................. 2

Kit Preparation ....................................................... 3

Kit Assembly

– ISO DIN radio provision with pocket ...................... 4

– ISO DDIN radio provision ...................................... 5

Axxess Interface Installation ................................ 6

Table of Contents

Note: The door on the factory pocket below the

radio will not function properly with the 99-7803G

installed. As an alternate solution, Metra offers the

88-00-7803 replacement pocket (sold separately).

Produkspesifikasjoner

Merke:	Metra
Kategori:	Bilsett
Modell:	99-7803G
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Kompatible produkter:	2003-07 Honda Accord
Produktfarge:	Sort
