Side 1/4
METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2015 METRA ELECTRONICS CORPORATION
REV. 4/14/2015 INST99-7808B
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
Installation instructions for part 99-7808B
• ISODINradioprovisionwithpocket
• DoubleDINradioprovision
• Painted to match factory finish
•A)Radiotrimpanel•B)Radiobrackets•C)Pocket•D)(8)#8x3/8”Phillipsscrews
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS(soldseparately)
WiringHarness:•70-1729
AntennaAdapter:•40-HD11(without OE nav)•40-HD12(with OE nav)
•Phillipsscrewdriver•Panelremovaltool
TOOLS REQUIRED
Acura TL 2009-2014
(Factory navigation is no longer operational with the use of this kit)
99-7808B
A
C
B
D
Dash Disassembly
– AcuraTL2009-2014............................................ 2
Kit Assembly
– ISO DINradioprovisionwithpocket...................... 3
– DoubleDINradioprovision................................... 3
Table of Contents
99-7808B
2
Dash Disassembly
1. Unclipandremovethe(2)side
panelsthatextendalongthecenter
consoleandupalongthesidesof
thefactoryradio.(FigureA)
2. Unclipandremovethea/cvent
panelabovethefactoryradio.
(FigureB)
3. Remove(4)8mmscrewssecuring
thefactoryradio.(FigureC)
4. Remove(3)Phillipsscrewsfrom
eacha/cbuttonpodthenunclip
andremovethepodsfromthe
factoryradiopanelassembly.
(FigureD)
Continue to kit assembly
(Figure A) (Figure C)
(Figure B) (Figure D)
