Side 1/56
opticalCON
optical
CON
®
Fiber optic connection system
FIBER OPTIC
SYSTEMS
2
SETTING
STANDARDS
SETTING
STANDARDS
2
www.neutrik.com 3opticalCON
®
- fiber optic connection system
Introduction ......................................................... 4
opticalCON Design Criteria .............................................5
opticalCON ADVANCED / LITE ........................................... 6
opticalCON Chassis .................................................... 7
opticalCON Mobile Field Cables .......................................... 8
opticalCON Custom Cable Assembly ..................................... 10
opticalCON ADVANCED Cable Connectors ................................. 12
Features & Benefits .......................................... 13
opticalCON DUO ADVANCED .................................. 14
opticalCON QUAD ADVANCED ................................. 16
opticalCON MTP
®
12 ADVANCED ................................ 18
opticalCON MTP
®
24 ADVANCED ................................ 20
opticalCON SPLIT & POWER SPLIT Cables .......................... 22
Breakout Adapter ........................................... 24
Accessories for opticalCON ADVANCED ...........................25
opticalCON LITE Cable Connectors ....................................... 26
Features & Benefits .......................................... 27
opticalCON DUO LITE ........................................ 28
opticalCON QUAD LITE ....................................... 30
opticalCON MTP
®
12 LITE ..................................... 32
opticalCON MTP
®
24 LITE ...................................... 34
opticalCON ADVANCED Chassis Connectors ................................ 36
Features & Benefits .......................................... 37
opticalCON DUO ADVANCED Chassis ............................ 38
opticalCON QUAD ADVANCED Chassis. . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
opticalCON MTP
®
12 ADVANCED Chassis ......................... 42
opticalCON MTP
®
24 ADVANCED Chassis .......................... 44
Accessories for Chassis ....................................... 46
opticalCON Coupler ..................................................46
opticalCON Transceiver Adapter ........................................47
opticalCON Breakout Adapter ..........................................47
opticalCON Breakout Box .............................................48
opticalCON powerMONITOR ........................................... 50
opticalCON Panel Solutions ............................................ 52
Fiber Optic Measurement & Cleaning Kit .................................. 54
Content PAGE
