WWW.LEGRAND.US/ONQ
On-Q 6 & 8-Port Network
Interface Modules are designed
to connect a Wi-Fi router or
switch to wired networking
locations throughout the home.
Terminate up to 8 data lines to
connect high-speed devices like
computers, smart TVs, gaming
systems and network streaming
devices to the home network and
ensure a future-proof connection
with maximum data throughput.
Available in 3 different module
types to support Cat 5e, Cat 6 or
Cat6a cable connections.
RELIABLE HOME
NETWORKING WITH
MAXIMUM DATA
THROUGHPUT.
FEATURES & BENEFITS
Supports punch down
termination of up to 8 data
lines for interface with home
network
Supports termination using
T568A wiring standard
UL Listed and exceeds TIA/EIA
568-C.2 industry standards
Fits all On-Q metal and plastic
structured wiring enclosures
Efficient installation with front
mounted 110-IDC terminals
and RJ45 connectors
Bracket made of reinforced
plastic to support proper
punch down terminations
and also maintain Wi-Fi
transparency when paired
with the plastic enclosure
Network Interface
Modules
AC1058
Cat 5e
AC1068
Cat 6
AC106A6
Cat 6a
WWW.LEGRAND.US/ONQ
Network Interface Modules
COMPLETE YOUR
INSTALLATION WITH
ON-Q UL-VERIFIED
PATCH CABLES.
Available in 1, 2, 3, 7, 14, 25 & 50
Foot Lengths
AC35XX-WH-V1
Cat 5e Patch Cables (White)
AC36XX-BE-V1
Cat 6 Patch Cables (Blue)
AC6AXX-GY-V1
Cat 6a Patch Cables (Gray)
800.223.4162
1.877.BY.LEGRAND
www.legrand.us
www.legrand.ca
© Copyright 2017 Legrand All Rights Reserved.
© Copyright 201
7 Tous droits réservés Legrand.
© Copyright 201
7 Legrand Todos los derechos reservados.
The
1507275 - REV C
3
40. 253
Attach a Cat5e / Cat6 patch cable from the RJ45 connector to a network router / switch to extend data connectivity to the corresponding location.
Fixez un câble de connexion Cat5e / Cat6 du connecteur du module à un routeur / commutateur pour étendre la connectivité des données à
l'emplacement correspondant.
Conecte un cable de conexión Cat5e / Cat6 del conector del módulo a un enrutador / conmutador para extender la conectividad de datos a la
ubicación correspondiente.
