STRUCTURED WIRING, CONNECTIVITY &
HOME THEATER SOLUTIONS
STRUCTURED WIRING
& CONNECTIVITY
GUIDE
WWW.LEGRAND.US/ONQ
2 3
ENCLOSURES ..................................................................................................... 4
PLASTIC ENCLOSURES ................................................................... 4
METAL ENCLOSURES ...................................................................... 11
ACCESSORIES ............................................................................................7
VIDEO & VOICE DISTRIBUTION....................................................13
VOICE & VIDEO MODULES .......................................................13
HOME NETWORKING .............................................................................14
NETWORK MODULES.....................................................................14
POWER MANAGEMENT .......................................................................15
DATA CONNECTIVITY ..............................................................................16
LOW VOLTAGE BRACKETS ......................................................16
KEYSTONE WALL PLATES .......................................................... 17
WALL PLATES ......................................................................................... 20
STRAPS.............................................................................................................21
SURFACE MOUNT BOXES ..........................................................21
PRE-MOLDED WALL PLATES & STRAPS ................. 22
PRE-CONFIGURED PLATES & STRAPS ..................... 23
HOME THEATER SOLUTIONS ....................................................... 23
AV CABLING ...................................................................................................... 26
HDMI CABLES ........................................................................................ 26
AUDIO/VIDEO CABLES ................................................................. 27
PATCH CABLES ..................................................................................... 26
CABLE TIES & PATCH PANELS .................................................... 28
INSTALLATION TOOLS & CONNECTORS ........................ 29
RESOURCES & SUPPORT .................................................................30
As the industry leader in structured wiring, Legrand provides
the proven, practical solutions preferred by installers and major
home builders across the country. Our comprehensive ON-Q product
oering — which includes wall plates, jacks, HDMI cables, straps,
tools, modules, enclosures & home theater solutionssimplifies
installations and reduces time on site. We specialize in meeting the
right specifications for any project — residential or light commercial
— with solutions that exceed your needs. From single-family homes
to apartments, townhomes to condominiums, Legrand has the
professional answer for any project.
SUPERIOR
INFRASTRUCTURE SOLUTIONS
WWW.LEGRAND.US/ONQ
4 5
The 9" & 17" Dual-Purpose In-Wall Enclosure
are engineered to provide storage of
structured wiring and AV components
Constructed of Wi-Fi transparent material
to manage wireless components and AV
devices at point-of-use locations
Available in 9" or 17" sizes, perfect for areas
directly behind a TV or other media locations
PART NO. DESCRIPTION
ENP0900-NA
Dual-Purpose 9" In-Wall Enclosure
ENP0905-NA-V1
Dual-Purpose 9" In-Wall Enclosure with
5" Mounting Plate
ENP1700-NA Dual-Purpose 17" In-Wall Enclosure
ENP1705-NA-V1 Dual-Purpose 17" In-Wall Enclosure with
5" Mounting Plate
PLASTIC ENCLOSURES
DUAL-PURPOSE ENCLOSURES
DESCRIPTION 20" Enclosure 30" Enclosure 42" Enclosure
Enclosure Dimensions 22.2" L x
17. 5" W x 5.5" D
32.2" L x
17. 5"W x 5.5" D
44.2" L x
17. 5"W x 5.5" D
Plastic Enclosure with Hinged Door & Trim Ring ENP2050-NA ENP3050-NA ENP4250-NA
Plastic Hinged Door & Trim Ring Only ENP2060-NA ENP3060-NA ENP4260-NA
Plastic Enclosure Only ENP2080-NA ENP3080-NA ENP4280-NA
Plastic Hinged Door & Trim Ring Only (Pack of 5) ENP20605-NA ENP30605-NA ENP42605-NA
Plastic Enclosure Only (Pack of 5) ENP20805-NA ENP30805-NA ENP42805-NA
Trim Ring, For Replacement Only ENP2001-NA ENP3001-NA ENP4201-NA
ENPNA
ENPNAV
AC
" Mounting Plate
ENPNAV
ENPNA
ENCLOSURES ENCLOSURES
The ON-Q line of plastic enclosures provide
Wi-Fi transparent infrastructure to properly
organize, protect & support the home’s
wired and wireless connected systems
Universal mounting grid maximizes compatibility with
third party products without additional brackets
Extra venting along vertical plane of door
allows for superior heat dissipation
Reversible door snaps easily into trim ring
without tools, swings a full 180 degrees
Lockable with included screws or
Optional Keyed Lock (364478-01)
