GUIDE SPECIFICATIONS
On-Q
®
Residential Multimedia Panels
Project Name Project No. Date
Project Location 27 11 16-1 Communications Cabinets, Racks, Frames,
& Enclosures
This guide specification is written according to the Construction Specifications Institute (CSI)
formats, including MasterFormat, SectionFormat, and PageFormat.
Carefully review and edit this section to meet the requirements of the project and local building
code. Coordinate this section with other specification sections and drawings.
Delete all "Specifier Notes" when done editing this section.
SECTION 27 11 16
COMMUNICATIONS CABINETS, RACKS, FRAMES, AND ENCLOSURES
PART 1 - GENERAL
1.1 CONDITIONS AND REQUIREMENTS
A. The General Conditions, Supplementary Conditions, and Division 01 – General
Requirements apply.
1.2 SECTION INCLUDES
Specifier Note: Delete items below that are not included in this section.
A. Residential multimedia panels (MMP).
B. [Insert item description.]
1.3 RELATED SECTIONS
Specifier Note: In this article, specify work specified in other sections that is related to work
of this section.
A. Division 26 - Electrical: Electrical systems and components.
B. Division 27 - Communications: Communications and audio-video systems and
components.
C. Division 28 - Electronic Safety and Security: Security systems and components.
Specifier Note: The following paragraph is a sample that may be used in this article. Add to
or delete from the following as appropriate for the specific project.
D. Section [xx xx xx] – [Section Title]: [Include brief description of work specified in
another section that is related to the work of this section.]
1.4 SUBMITTALS
Specifier Note: In this article, specify various types of data to be furnished by the contractor
before, during, or after construction. Topics included in this article are: product data, shop
drawings, samples, design data, test reports, certificates, manufacturers’ instructions, manu-
facturers’ field reports, qualification statements, and closeout submittals.
A. Submit under provisions of Section [01 33 00] [______].
B. Product Data: Submit for residential multimedia panels and components.
C. Shop Drawings: For the following electrical system components. Include plans,
elevations, sections, details, and attachments to other work.
1. Residential multimedia panels.
GUIDE SPECIFICATIONS
On-Q
®
Residential Multimedia Panels
Project Name Project No. Date
Project Location 27 11 16-2 Communications Cabinets, Racks, Frames,
& Enclosures
D. Samples: Submit three (3) [___________] with required color and finish. Show
standard color ranges available.
1.5 QUALITY ASSURANCE
Specifier Note: In this article, describe qualifications, regulatory requirements, certifications,
field samples, mock-ups, and pre-installation meetings.
A. Manufacturers: Firms regularly engaged in manufacture of residential multimedia
panels and components of the types and sizes required, whose products have been in
satisfactory use in similar service for not less than 10 years. Provide residential
multimedia panels and components produced by a manufacturer listed in this section.
B. Source Limitations: Obtain each type of residential multimedia panel and components
through one (1) source from a single manufacturer.
C. Residential Multimedia Panels and Components: Comply with requirements of
applicable local codes, NEC, UL, ETL, EIA, TIA, and NEMA Standards pertaining to
residential multimedia panels and components. UL and/or cUL classified. Comply with
NFPA 70.
1.6 DELIVERY, STORAGE AND HANDLING
A. Deliver residential multimedia panels and components in factory labeled packages.
B. Store and handle in strict compliance with manufacturer’s written instructions and
recommendations.
C. Protect from damage due to weather, excessive temperature, and construction
operations.
PART 2 - PRODUCTS
2.1 MANUFACTURERS
A. Basis-of-Design Product: The design for residential multimedia panels is based on
products manufactured by Legrand
®
, 301 Fulling Mill Rd, Suite G, Middletown, PA
17057; toll-free 800-321-2343; Web Site: http://www.legrand.us/onq.
B. Substitutions will be considered under provisions of Section 01 25 00.
2.2 RESIDENTIAL MULTIMEDIA PANELS (MMP)
A. Residential Multimedia Panels, General: On-Q
®
Residential Multimedia Panels (MMP)
provide a central distribution point for home or small office technologies. The
enclosures accommodate distribution of voice, data, video, audio, security, and control
applications.
B. Metal Enclosures, General: Fabricated from 20 gauge cold-rolled steel with protective
powder coat finish, glossy white color and provided with matching hinged flanged cover
with lock.
1. Mounting slots on enclosure permit adjustment for different gypsum board
thicknesses. Provide 1/2-inch, 5/8-inch, and 3/4-inch depth marks on enclosure
for alignment.
2. Lance slots within enclosure for hook-and-loop fastener or vinyl cable ties.
3. Flush mount cover overlaps 3/4-inch to hide gypsum board cuts around the
MMP.
GUIDE SPECIFICATIONS
On-Q
®
Residential Multimedia Panels
Project Name Project No. Date
Project Location 27 11 16-3 Communications Cabinets, Racks, Frames,
& Enclosures
4. Enclosure ships with cardboard insert to prevent debris or paint over-spray from
entering the MMP during rough-in stage of installation.
5. Provide mounting hooks on cover to align screw holes for ease of installation.
6. Multiple knockouts on enclosure support conduit up to two (2) inches in diameter
and facilitate cable routing and entry.
7. Holds 1/4, 1/2 and full-width expansion modules with ability to mount most
modules either vertically or horizontally.
8. Provide for bonding and grounding to meet TIA/EIA 606 Standards.
9. Conformance with Standards: Comply with TIA/EIA 568-A and TIA/EIA 570-A
requirements and meet FCC Part 68.
10. Enclosure to be UL listed in accordance with ANSI/UL 985, ANSI/UL 1023,
CAN/CSA-C22.2 No. 182.4-1990, ULC-S545, and CSA-C22.2 No. 144.1 (2006).
Specifier Note: Enclosure size, data module, voice module, and video module selection will
depend on application variables, such as fiber or copper, Cat 5e, Cat 6, or Cat 6a, size of
residence, etc. Retain as many of the following five (5) enclosures as required for a specific
project and delete the others.
Specifier Note: The enclosures in the five (5) paragraphs can accommodate a variety of
modules. Select desired modules from Article 2.3 below.
Specifier Note: The 14"-42" metal enclosures the five (5) paragraphs below are also available
with screw on doors (ENXX00), enclosure only (ENXX80), hinged cover only (ENXX60),
screw on cover only (ENXX20), and an enclosure with knockouts (ENXX85). Revise the cata-
log number and description accordingly to reflect the type of enclosure desired.
C. Metal Enclosures:
1. 42" Enclosure: Catalog No. EN4250 enclosure with hinged cover and lock;
minimum dimensions shall be 42" H x 14.25" W x 3.6" D.
2. 28" Enclosure: Catalog No. EN2850 enclosure with hinged cover and lock;
minimum dimensions shall be 28" H x 14.25" W x 3.6" D.
3. 20" Enclosure: Catalog No. EN2050 enclosure with hinged cover and lock;
minimum dimensions shall be 20" H x 14.25" W x 3.6" D.
4. 14" Enclosure: Catalog No. EN1450 enclosure with hinged cover and lock;
minimum dimensions shall be 14" H x 14.25" W x 3.6" D.
D. Plastic Enclosures for General Structured Wiring, General: Fabricated from UL-rated
ABS plastic, paintable white color and provided with matching hinged flanged cover.
Enclosure accommodates both wired structured wiring systems and wireless
networking equipment. Complies with UL60950-1 and CAN/CSA C22.2 No. 60950-01-
07. RoHS Compliant.
1. Plastic enclosure allows wireless devices such as access points to secure in
cabinet without degrading network performance.
2. Enclosure can be surface or flush mounted. Staggered tabs allow side-by-side
installation of multiple enclosures.
3. Meets or exceeds requirements of UL Standard 2416. For use in non-fire-rated
walls.
4. Universal mounting grid compatible with distribution modules from multiple
manufacturers.
