Side 1/4
www.avsl.com 150.466UK User Manual
Dazzler
80W LED RGBWA Moving Head
Item ref: 150.466UK
User Manual
Dazzle your venue with bright and colourful washes using this compact moving head unit comprising a
powerful 80W 5-colour COB LED. Easily operated using internal auto or sound to light programs or by
11/14 channel DMX connection for more precise control, the unit can be free standing or mounted to
trussing using the supplied brackets and is ideal for small stages, bars, nightclubs and mobile DJs.
In the box:
Your Dazzler should arrive with you in a single carton in good condition. The carton should contain
1 x main unit with bracket, 1 x UK IEC mains lead and 1 x manual.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally. Qualified personnel should then
check the unit before continuing use.
Please read through this manual thoroughly before use, any damage
caused by misuse of product will not be covered by warranty.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com 150.466UK User Manual
Placement:
• Use the included mounting bracket to fix to a stand or lighting truss.
• Use secondary safety fixings if mounting overhead.
• Keep away from damp or dusty environments.
• Ensure adequate airflow around the fixture housings.
• Ensure adequate access to controls and connections.
• Do not aim LED output directly into line of sight, as this can result in eye injury.
Cleaning:
• Use a soft cloth with a neutral detergent to clean the casing as required.
• Use a vacuum cleaner to clear ventilation grilles of any dust or debris build-ups.
• Do not use strong solvents for cleaning the unit.
Rear panel and control:
1.
Menu button
2.
Up button
3.
Down button
4.
LED display
5.
Enter button
6.
Microphone
7.
DMX input
8.
DMX output
9.
IEC input (110-240 Vac, 50/60 Hz)
Manual control menu:
Press the “MENU” button to enter the settings menu.
Press “UP” and “DOWN” buttons to navigate through various setting functions.
Press “ENTER” button to confirm the desired setting:
1.
2.
3.
4.
5.
6.
7.
8.
9.
