www.avsl.com 151.735UK User Manual
PAR-T Bar
LED Party Bar and Stand Kit
Item ref: 151.735UK
User Manual
Perfect for home parties and smaller venues the QTX PAR-T Bar and
stand kit comes in one convenient package. The bar itself comprises of 2
colourful magic ball effects and 14 bright LED PAR lights which combine
to provide an array of dazzling patterns and effects. A simple switch on
the back of the unit provides the choice of various automatic colour
changing modes or a sound to light function. The included remote control
offers an even wider variety of features making the PAR-T Bar perfect for
both home or professional use.
In the box:
Your PAR-T Bar should arrive with you in a single carton in good
condition. The carton should contain 1 x main unit, 1x floor stand, 1x
tripod mounting bracket, 1x mounting bracket, 1x remote control and 1 x
user guide.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect from the mains and allow the unit to dry out naturally. Qualified personnel should
then check the unit before continuing use.
Placement:
• Use the tripod fixing bracket to attach to the included adjustable floor stand.
• Ensure the unit and stand are positioned away from walkways and places where it could be tripped
on or knocked over.
• Alternatively use the included mounting bracket to fix to a stand or lighting truss.
• Keep away from damp or dusty environments.
Usage Instructions:
• Connect the unit to the mains power supply and switch on.
• Use the switch on the back of the unit to choose between auto and sound to light modes, along with
master power off.
• Please note: the supplied remote control will only work when the switch on the back of the unit is
set to auto or sound to light modes.
Please read through this manual thoroughly before use, any damage
caused by misuse of product will not be covered by warranty.
www.avsl.com 151.735UK User Manual
Remote control:
The PAR-T Bar is supplied with an I.R. remote control for quick access to the extended functions of the
unit. This has a maximum range of approximately 4-5m and must be aimed towards the front of the unit.
Controls and functions are listed on the diagram below:
Specifications:
Power
AC110-240Vac, 50/60Hz
Power consumption
60W
LED power
14x 1W RGB LED + 2x 3x3W RGB LED Magic Ball
Modes
Auto, sound activated
Beam Angle
25°
Height adjustment
710 to 1680mm
Dimensions (PAR bar)
385 x 95 x 90mm
Lead length
2m
Weight
1.6kg
This product is classed as Electrical or Electronic equipment and should not be disposed
with other household or commercial waste at the end of its useful life.
The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted.
Copyright© 2022 AVSL Group Ltd, Unit 2 Bridgewater Park, AVSL (Europe) Ltd, Unit 3D North Point House,
Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland.
1. ON/OFF = Remote on/off
2. AUTO MIX = Auto show mode
3. PAR = PAR auto show mode
4. PAR = PAR sound active mode
5. LED = Pattern auto show mode
6. COLOR -- = Auto show decrease speed
7. MOTOR -- = Effect motor decrease speed
8. SEN -- = Sound active decrease sensitivity
9. SOUND MIX = PAR and Effects sound
active mode
10. PAR JUMP = PAR colour change mode
11. GRADUAL = PAR colour fade mode
12. LED = Effect sound active mode
13. FLASH = PAR strobe mode
14. COLOR + = Auto show increase speed
15. MOTOR + = Effect motor increase speed
16. SEN + = Sound active increase sensitivity
1.
2.
3.
4.
5.
6.
7.
9.
10.
11.
12.
13.
14.
15.
8.
16.
