www.avsl.com 151.675UK User Manual
PAR10-RGBW
10W LED RGBW Spotlight
Item ref: 151.675UK
User Manual
A compact single LED spotlight, ideal for performances and venues or to use with a mirror ball. Supplied
with an easy-to-use remote control which enables you to switch between RGBW solid colours or various
colour change options. Fitted with a bright 10W LED the lightweight plastic housing generates virtually no
heat and comes fitted with a 1m power lead.
In the box:
Your PAR10-RGBW should arrive with you in a single carton in good condition. The carton should contain
1 x main unit with bracket and thumbscrew, 1x remote control and 1 x user guide.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the charging lead and allow the unit to dry out naturally. Qualified personnel
should then check the unit before continuing use.
Placement:
• Use the included mounting bracket to fix to a stand or lighting truss.
• Keep away from damp or dusty environments.
Please read through this manual thoroughly before use, any damage
caused by misuse of product will not be covered by warranty.
www.avsl.com 151.675UK User Manual
Remote control:
The PAR10-RGB is supplied with an I.R. remote control for quick access to all functions of the unit. This
has a maximum range of approximately 4-5m and must be aimed towards the front of the housing. The
Controls and functions are listed on the diagram below:
Specifications:
Power
100 - 240Vac, 50/60Hz
Power consumption
10W
LED: spot
1pcs LED RGBW
Effective distance
Up to 6m
Beam angle: spot
5°
Modes
Solid colour (RGBW) and auto gradual/jump/breathe effects
Lead Length
1m
Remote battery
CR2025 (supplied)
Dimensions
165 x 68 x 68mm
Weight
380g
This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at
the end of its useful life. The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted.
Copyright© 2022 AVSL Group Ltd, Unit 2 Bridgewater Park, AVSL (Europe) Ltd, Unit 3D North Point House,
Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland.
1. OFF = Lamp off
2. R = Red static
3. G = Green static
4. Gradual = Gradual colour change
mode
5. Jump = Colour jump mode
6. Speed – = Decrease speed in auto
modes
7. Mode – = Decrease value in manual
colour switching (RGBW)
8. On = Lamp on
9. W = White static
10. B = Blue static
11. Breathe = Colour breathe mode
12. Speed + = Increase speed in auto
modes
13. Mode + = Increase value in manual
colour switching (RGBW)
1.
2.
3.
4.
5.
6.
7.
9.
8.
11.
12.
13.
10.
