www.avsl.com 151.742UK User Manual
Gobo Fireflash
4 in 1 LED and Laser Effect light
Item ref: 151.742UK
User Manual
Thank you for choosing the QTX Gobo Fireflash LED and Laser Effect Light. A compact and robust metal
4-in-1 light effect, combining 6 moving colour gobos, 3 colour Effect ball, a 20W White Strobe LED and
Dual colour Laser in a compact and convenient package. Easy Setup with auto-run, sound activation and
14 Channel DMX control.
In the box:
Your Gobo Fireflash should arrive with you in a single carton in good condition. The carton should contain
1 x main unit with bracket, 1 x UK IEC mains lead and 1 x manual.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally. Qualified personnel should then
check the unit before continuing use.
Please read through this manual thoroughly before use, any damage
Caused by misuse of product will not be covered by warranty.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com 151.742UK User Manual
Caution: Laser radiation
Avoid pointing directly towards eyes. Laser output can cause injury if viewed directly.
This product is a Class 3B laser and should only be installed and used by persons who
are trained in the management of laser radiation and are able to operate in accordance
within the guidance given by the Health and Safety Executive (HSE) in HS(G)95: “The
Radiation Safety of Lasers used for Display purposes”. Copies of this guide can be
downloaded from: www.avsl.com/assets/documents/hsg95.pdf
Placement:
• Use the included mounting bracket to fix to a stand or lighting truss
• Use secondary safety fixings if mounting overhead.
• Keep away from damp or dusty environments
• Ensure adequate air-flow around the fixture housings
• Ensure adequate access to controls and connections
• Do not aim LED or laser output directly into line of sight, as this can result in eye injury.
Cleaning:
• Use a soft cloth with a neutral detergent to clean the casing as required
• Use a vacuum cleaner to clear ventilation grilles of any dust or debris build-ups
• Do not use strong solvents for cleaning the unit
Rear panel controls:
1. IEC mains in
2. Laser key
3. DMX signal in
4. DMX signal out
5. Earth screw (DO NOT
REMOVE)
6. Manual control buttons
7. LCD display
Manual control menu:
Press the “MENU” button to enter the settings menu.
Press “UP” and “DOWN” buttons to navigate through various setting functions.
Press “ENTER” button to confirm the desired setting.
2.
1.
3.
4.
5.
6.
7.
