www.avsl.com 154.042UK User Manual
PAR-186
High Power RGBWA-UV PAR Can
Item ref: 154.042UK
User Manual
Thank you for choosing the PAR-186, A lightweight, high output LED PAR can fitted with 12pcs of 15W
super bright 6-in-1 COB LEDs. This light can be controlled manually via the controls on the back of the
unit, by the internal automatic or sound-activated programs or with a DMX controller if more precise
control is preferred. The tough plastic housing is accompanied by a flexible plastic mounting bracket,
giving the whole unit a total of weight of only 1.25Kg. Ideal solution for parties and events where
background colour wash or U/V illumination is required.
In the box:
Your PAR-186 should arrive with you in a single carton in good condition. The carton should contain
1 x main unit with bracket and screws, 1 x UK IEC mains lead and 1 x user guide.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally. Qualified personnel should then
check the unit before continuing use.
Please read through this manual thoroughly before use, any damage
caused by misuse of product will not be covered by warranty.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com 154.042UK User Manual
Placement:
• Use the included mounting bracket to fix to a stand or lighting truss
• Keep away from damp or dusty environments
• Ensure adequate airflow around the fixture housings
• Ensure adequate access to controls and connections
Cleaning:
• Use a soft cloth with a neutral detergent to clean the casing as required
• Use a vacuum cleaner to clear ventilation grilles of any dust or debris build-ups
• Do not use strong solvents for cleaning the unit
Rear panel controls:
1. Manual control buttons
2. IEC power in (fused)
3. LCD display
4. DMX input
5. DMX output
Manual control menu:
Press the “MENU” button to enter the settings menu.
Press “UP” and “DOWN” buttons to navigate through various setting functions.
Press “ENTER” button to save the desired setting.
Menu
Number range
Function and description
d001
d001-d512
DMX512 address setting (6 channel mode)
A001
A001-A512
DMX512 address setting (10 channel mode)
2.
5.
3.
4.
1.
