Side 1/4
www.avsl.com 151.556UK User Manu
Safety Instructions
• Please keep this manual for future reference.
• Always make sure that you are connecting to the proper voltage, and that the line voltage you are
connecting to is not higher than that stated on the bottom of the fixture.
• This product is intended for indoor use only. It must be connected to an earthed mains outlet.
• To prevent risk of fire or shock, do not expose fixture to rain or moisture. Make sure there are no
flammable materials close to the unit while operating.
• The unit must be installed in a location with adequate ventilation, at least 20cm from adjacent surfaces. Be
sure that no ventilation slots are obstructed.
• Always disconnect from power source before servicing or replacing fuse and be sure to replace with same
fuse size and type.
• Maximum ambient temperature is 40°C. Do not operate the fixture at higher temperatures.
• In the event of a serious operating problem, stop using the unit immediately. Never try to repair the unit by
yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the
nearest authorised technical assistance centre.
• Make sure the power cord is never crimped or damaged.
• Never disconnect the power cord by pulling or tugging on the cord.
• Avoid direct eye exposure to the light source while it is on.
DMX-512 connection
If you are using a standard DMX controller, you can connect the DMX output from the controller directly to the
DMX input of the first unit in the DMX chain. Connect the DMX output of the first unit in a DMX chain with the
DMX input of the next unit in the chain. Always connect the output of one unit with the input of the next unit
until all units are connected.
Number
Item
Function
1
Power supply input
Attach the IEC mains cable here.
2
DMX input
3 pin XLR connector for DMX 512 input communication.
3
DMX output
3 pin XLR connector for DMX512 output communication.
4
LED display
LED function display and menu buttons to control the operating
mode of the unit.
5
MENU buttons
MENU function buttons Menu, Up, Down Enter
6
Microphone
Built-in microphone for Sound-to-Light operation.
7
Par can mounts
Attach the par can lights to the controller bar
8
Par can connections
Attach the par can cables to the controller bar
9
Light stand socket
Tighten screw to secure the controller bar to the light stand.
