www.avsl.com 151.546UK User Manual
Recharge Performer
LED PAR Bar with Tripod
Item ref: 151.546UK
User Manual
Ideal for performers, this complete portable lighting set
comprising 4 RGBW PAR lights is powered from a rechargeable
T-bar with an internal lithium battery that provides up to 6
hours use without the need for additional power. Easily
controlled via DMX, infra-red remote control or internal auto
and sound-activated programs selectable from the rear control
panel. Each lighting fixture is angle-adjustable to distribute
colour washes around the room. Supplied with 2.3m telescopic
tripod stand and carry bags making it ideal for transporting to
venues and events where power isn't readily available.
In the box:
Your Recharge Performer should arrive with you in a single carton in good condition. The carton should
contain: 1 x T-bar with 4 RGBW PAR cans attached, 1 x 2.3m Tripod Stand, 1 x Remote Control, 1 x UK
3m IEC mains lead, 1 x T-Bar Carry Bag, 1 x Tripod Stand Carry Bag and 1 x user manual.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally. Qualified personnel should then
check the unit before continuing use.
Please read through this manual thoroughly before use, any damage
caused by misuse of product will not be covered by warranty.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com 151.546UK User Manual
Placement:
• Open the included tripod stand legs onto the floor ensuring the thumbscrews are tightened and it’s
set down on a flat stable surface away from walkways or where it can be easily knocked over.
• Attach the T-Bar to the top of the stand and tighten the thumbscrew ensuring its secure.
• Keep the unit away from damp or dusty environments.
• Ensure adequate air-flow around the fixture housings.
• Ensure adequate access to controls and connections.
• Do not aim LED or laser output directly into line of sight, as this can result in eye injury.
Cleaning:
• Use a soft cloth with a neutral detergent to clean the casing as required.
• Use a vacuum cleaner to clear ventilation grilles of any dust or debris build-ups.
• Do not use strong solvents for cleaning the unit.
Rear panel and controls:
1.
Power switch
2.
IEC input (110-240 Vac, 50/60 Hz)
3.
Earth screw (do not remove)
4.
DMX input
5.
DMX output
6.
Control panel
7.
LED display
8.
Microphone
9.
Battery charge status
Manual control menu:
Press the “MENU” button to enter the settings menu.
Press “UP” and “DOWN” buttons to navigate through various setting functions.
Press “ENTER” button to confirm the desired setting.
Sequence
Number
Display
Sub-Menu
Function/Action
1
d001 – d512
001 - 512
DMX address setting
2
IP.01 – IP.64
001 -512
IP mode
3
A1.01
A1.01 – A1.18
Static Colour. Select one of 18 colour options
4
A2.01
A2.01 – A2.32
Colour Jump. A2.01 (slowest) A2.32 (fastest)
5
A3.01
A3.01 – A3.19
Multi Colour. Different Colour selection available
1.
2.
3.
4.
5.
6.
7.
8.
9.
