Side 1/5
www.avsl.com 154.055UK User Manual
SpectraWash
240W LED Colour Blinder and Strobe
Item ref: 154.055UK
User Manual
The SpectraWash is a powerful 240W Multicolour LED stage-blinder that can produce a vast array of
moving effects, strobes and washes. Easy to setup and use via a wide range of integrated automatic and
sound to light programs or for more precise control there are 4 DMX modes to choose from. Fitted with
twist and lock power connections for a more professional feel and housed in an all-metal casing with fan
cooling for durability and reliable operation.
In the box:
Your SpectraWash should arrive with you in a single carton in good condition. The carton should contain
1 x main unit, 1 fixing bracket with thumbscrews, 1 x twist and lock UK mains lead and 1 x user guide.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally. Qualified personnel should then
check the unit before continuing use.
Please read through this manual thoroughly before use, any damage
caused by misuse of product will not be covered by warranty.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com 154.055UK User Manual
Placement:
• Use the included mounting bracket to fix to a stand or lighting truss.
• Use secondary safety fixings if mounting overhead.
• Keep away from damp or dusty environments.
• Ensure adequate airflow around the fixture housings.
• Ensure adequate access to controls and connections.
• Do not aim LED output directly into line of sight, as this can result in eye injury.
Cleaning:
• Use a soft cloth with a neutral detergent to clean the casing as required.
• Use a vacuum cleaner to clear ventilation grilles of any dust or debris build-ups.
• Do not use strong solvents for cleaning the unit.
Rear panel controls:
1. Power input (twist and lock)
2. Power output (twist and lock)
3. Fan ventilation (do not cover)
4. DMX input
5. DMX output
6. Led display
7. Control panel
Manual control menu:
Press the “MENU” button to enter the settings menu.
Press “UP” and “DOWN” buttons to navigate through various setting functions.
Press “ENTER” button to confirm the desired setting.
Function
Description
A001-A512
DMX address settings
CH03-CH39
Switch between CH04, CH11, CH32 and CH39 then
press Enter key to save (default CH11)
1.
2.
3.
4.
5.
6.
7.
