Side 1/4
Power requirements
ENGLISH U.S. EU UK AU
PoE source (PSE) @OUT
ethernet port
Class 0~3 (802.3af)
Output power @OUT
ethernet port
15.4W
Output voltage @OUT
ethernet port
44 ~ 57VDC
Input voltage 100~125VAC 50~60Hz 220~250 VAC 50~60Hz
Power consumption @
OUT no load
2 W max
Power consumption @
OUT full load
21 W max
AC socket output current 100~125VAC max 10A 220~250VAC max 16A 220~250VAC max 11A 220~250VAC max 10A
DEUTSCH FRANÇAIS ITALIANO ESPAÑOL EU
PoE-Quelle (PSE) @OUT
Ethernet-Port
Source PoE (PSE) @OUT
port Ethernet
Sorgente PoE (PSE) porta
Ethernet @OUT
Fuente PoE (PSE) @OUT
puerto ethernet
Class 0~3 (802.3af)
Ausgangsleistung @OUT
Ethernet-Port
Puissance de sortie @
OUT port Ethernet
Potenza in uscita @OUT
porta Ethernet
Potencia de salida @OUT
puerto ethernet
15,4W
Ausgangsspannung @
OUT Ethernet-Port
Tension de sortie au port
Ethernet OUTrée
Voltaggio in uscita sulla
porta Ethernet OUT
Voltaje de salida @OUT
puerto ethernet
44 ~ 57VDC
Eingangsspannung Tension d'entrée Tensione di ingresso Voltaje de entrada 220~250 VAC 50~60Hz
Stromverbrauch @OUT
ohne Last
Consommation électrique
@OUT sans charge
Consumo energetico @
OUT senza carico
Consumo de energía @
OUT sin carga
2 W max
Stromverbrauch bei
Volllast
Consommation électrique
@OUT pleine charge
Consumo energetico @
OUT a pieno carico
Consumo de energía @
OUT carga completa
21 W max
Ausgangsstrom der AC-
Buchse (Wechselstrom)
Courant de sortie de la
prise AC (CA)
Corrente di uscita della
presa AC (CA)
Corriente de salida del
enchufe de AC (CA)
220~250VAC max 16A
ENGLISH
Copyright, trademarks, legal disclaimers
© 2024 Snom Technology GmbH. All Rights Reserved.
Snom, the names of Snom products, and Snom logos are
trademarks owned by Snom Technology GmbH. Snom, the
names of Snom products, and Snom logos are trademarks
owned by Snom Technology GmbH.
All product specications are subject to change without
notication. Snom Technology GmbH reserves the right to
revise and change this document at any time, without being
obliged to announce such revisions or changes beforehand
or after the fact.
Although due care has been taken in the compilation and
presentation of the information in this document, the data
upon which it is based may have changed in the meantime.
Snom therefore disclaims all warranties and liability for
the accurateness, completeness, and currentness of the
information published, except in the case of intention or
gross negligence on the part of Snom or where liability
arises due to binding legal provisions.
Important information
Please read the instructions on safety and disposal and on
how to set up and use the device before using it and also
give them to other users to read or inform those users of
their contents.
The nameplate is located at the bottom or rear of the
product.
Safety instructions
• Warning: Changes or modications to this unit
not expressly approved by the party responsible
for compliance could void the user's authority to
operate the equipment.
• Warning: The product is to be connected only to
PoE networks without routing to the outside plant.
• Mount the device only at heights not exceeding 2m.
• Follow the instructions in this manual and other
applicable documentation of the device.
• This device is for indoor use only! NOT FOR OUT-
DOOR USE!
• Do not install the device in rooms with high
humidity (for example, in bathrooms, laundry
rooms, damp basements). Do not immerse the
device in water and do not spill or pour liquids of
any kind onto or into the device.
• Do not install the device in surroundings at risk
for explosions (paint shops, for example). Do not
use the device if you smell gas or other potentially
explosive fumes.
• Do not use the device during thunderstorms.
Lightning striking the power grid may cause electric
shocks.
• Safety status of input/output connections comply
with SELV (Safety Extra Low Voltage) requirements.
Warning: To avoid electric shock, do not connect safety
extra-low voltage (SELV) circuits to telephone-network
voltage (TNV) circuits. LAN ports contain SELV, PSTN
ports TNV circuits. Some LAN and PSTN ports both use
RJ-45 connectors. Use caution when connecting cables.
Standards conformance
This device complies with the essential
health, safety, and environmental
requirements of all relevant European
directives and UK and Australian legislation.
The declaration of conformity can be
downloaded at
https://www.snom.com/conformity.
Unauthorized opening, changing, or modifying the
device will cause the warranty to lapse and may
result in the loss of conformity. In case of malfunction
contact authorized service personnel, your seller, or
Snom.
FCC part 15
This equipment has been tested and found to comply
with the requirements for a Class B digital device
under Part 15 of the Federal Communications
Commission (FCC) rules.
These requirements are intended to provide
reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
◦Reorient or relocate the receiving antenna.
◦ Increase the separation between the equipment
and receiver.
◦ Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is
connected.
◦ Consult the dealer or an experienced radio/TV
technician for help.
Changes or modications to this equipment not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation.
Privacy of communications may not be ensured when
using this equipment.
Industry Canada
This Class B digital apparatus complies with Canadian
requirements:
CAN ICES-3 (B)/NMB-3(B)
Cet appareil numérique de la classe B est conforme à
la norme
CAN ICES-3 (B)/NMB-3(B)
This device contains licence-exempt transmitter(s)/
receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt
RSS(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of
the device.
The term ‘’IC:‘’ before the certication/registration
number only signies that the Industry Canada
technical specications were met. This product meets
the applicable Innovation, Science and Economic
Development Canada technical specications.
Technical specications
• Safety: IEC 62368-1
• Operating temperature: 0–35 °C (32 °F–89.6 °F)
• Storage temperature: -10 °C–45 °C (14 °F–113 °F)
• Ethernet: 10/100/1000 Mbps
• Connectors:
◦2 x RJ-45
◦Power plug appropriate for your country
◦Power socket appropriate for your country
• Power: see table C, Power requirements
Disposal
This device is subject to European Directive
2012/19/EU and may not be disposed of with
general household garbage. If you do not know
where to dispose of the device at the end of
its life-span, contact your municipality, local waste
management provider, or vendor.
In countries outside the European Union disposal
should be done in line with local regulations. Please
contact local authorities for further information.
Cleaning
To clean the device, use an anti-static cloth. Please
avoid cleaning liquids as they might damage the
surface or internal electronics of the device.
For further information, please refer to our web page
https://service.snom.com.
DEUTSCH
Copyright, Markenrechte, Haftungsausschluss
© 2024 Snom Technology GmbH. Alle Rechte reser-
viert.
Snom sowie die Namen der Snom-Produkte und die
Snom-Logos sind gesetzlich geschützte Marken der
Snom Technology GmbH.
Produktspezikationen können ohne Vorankündigung
geändert werden. Snom Technology GmbH behält sich
jederzeit das Recht auf Überarbeitung und Änderung
dieses Dokumentes vor, ohne verpichtet zu sein, die
vorgenommenen Änderungen anzukündigen oder
mitzuteilen.
Trotz der angewandten Sorgfalt bei der Zusammen-
stellung und Präsentation der Informationen in diesem
Dokument können sich Daten zwischenzeitlich geändert
haben. Daher übernimmt Snom keine Gewähr für
die Richtigkeit, Vollständigkeit oder Aktualität der zur
Verfügung gestellten Informationen. Jegliche Haftung
für Schäden ist ausgeschlossen, sofern diese nicht auf
Vorsatz oder grober Fahrlässigkeit auf seiten von Snom
beruhen oder sofern keine Haftung aufgrund zwingen-
der gesetzlicher Bestimmungen eintritt.
Wichtige Hinweise
Lesen Sie bitte vor Inbetriebnahme die Sicherheits-
hinweise und die Bedienungsanleitung. Lassen Sie sie
auch von den Mitbenutzern des Gerätes lesen oder in-
formieren Sie sie über deren Inhalt.
Das Typenschild bendet sich unten oder hinten am
Gerät.
Sicherheit
Befolgen Sie die Anweisungen in dieser Bedienungsan-
leitung und in der sonstigen Dokumentation des Geräts.
• Warnung: Das in diesem Handbuch enthaltene Produkt
darf nur an PoE-Netzwerke ohne Routing zur Außenan-
lage angeschlossen werden.
• Die Steckdose für das Netzteil muss sich in der Nähe
des Geräts benden und leicht zugänglich sein.
• Montieren Sie das Gerät nur in Höhen von höchstens
2 m.
• Falls die Stromversorgung nicht über ein Ether-
netkabel erfolgt, verwenden Sie nur ein von Snom
ausdrücklich empfohlenes Netzteil. Die Verwendung
anderer Netzteile könnte das Telefon beschädigen
oder gar zerstören.
• erlegen Sie die Netz- und Stromkabel so, dass sie V
durch mechanischen Druck nicht beschädigt werden
und Personen nicht darüber stolpern könnten.
PoE Injector
Quick Installation Guide
A5E
A
B
C
Quick Installation
Guide
A5E
Delivery content · Lieferumfang · Contenu de la boîte · En la caja · Contenuto della confezione
Snom Technology GmbH
Aroser Allee 66
13407 Berlin, Deutschland
oce.de@snom.com
Snom Technology GmbH
Via Milano 1
20020 Lainate, Italia
oce.it@snom.com
Snom Technology GmbH
The Courtyard
High Street
Ascot, Berkshire SL5 7HP, UK
oce.uk@snom.com
SnomTechnology GmbH
130, avenue Joseph Kessel
78960 Voisins-le-Bretonneux
France
oce.fr@snom.com
VTech Communications Inc.
Snom Americas
9020 Washington Square Road,
Suite 555
Tigard, OR 97223
Phone support: (339) 227 6160
VTech Technologies Canada Ltd.
Suite 222
13888 Wireless Way
Richmond, B.C. V6V 0A3, Canada
Phone support: (339) 227 6160
Manufacturer:
VTech Telecommunications Ltd
23/F., Tai Ping Industrial Centre,
Block 1
57 Ting Kok Road, Tai Po
HONG KONG
EU
or UK or AUS
or U.S.
• The box contains the device appropriate for your country.
• Die Lieferung enthält das für Ihr Land passende Gerät.
• La boîte contient l'appareil adapté à votre pays.
• La confezione contiene il dispositivo addato al tuo paese.
• La caja contiene el dispositivo adecuado para su país.
LED Pattern Description
Ethernet
Steady green PoE device is connected
O Power o, or•
• no PoE device connected, or
• PoE device overload
Connecting · Anschließen · Connecter · Conectar · Collegare
or
PoEEthernet
v2024003
Weiter auf der Rückseite
Produkspesifikasjoner
| Merke: | Snom |
| Kategori: | Ikke kategorisert |
| Modell: | A5E |
Trenger du hjelp?
Hvis du trenger hjelp med Snom A5E still et spørsmål nedenfor, og andre brukere vil svare deg
Ikke kategorisert Snom Manualer
11 Oktober 2025
6 Oktober 2025
6 Oktober 2025
5 Mars 2025
5 Mars 2025
6 Januar 2025
6 Januar 2025
6 Januar 2025
6 Januar 2025
6 Januar 2025
Ikke kategorisert Manualer
- Brändi
- Miniland
- Pfister
- Lancom
- Ambient Weather
- Lazer
- Boneco
- Michael Todd Beauty
- Troy-Bilt
- Spanninga
- Salus
- Bresser
- Revell
- Millenium
- Pure 100
Nyeste Ikke kategorisert Manualer
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
