Quick Installation Guide
(1)
If no PoE available
- Wenn PoE nicht ver-
fügbar
- S'il n'y a pas de PoE
- Si no se dispone de
PoE
- Se non disponibile PoE
(2)
Not included in delivery
- Nicht im Lieferumfang
enthalten
- Non inclus
- Non incluido
- Non incluso
(3)
Optional - Optionnel -
Opzionale - Opcional
C
Connecting · Anschließen · Connecter · Conectar ·
Collegare
ENGLISH
Copyright, Trademarks, Legal Disclaimers
© 2024 Snom Technology GmbH. All Rights Reserved.
Snom, the names of Snom products, and Snom logos are
trademarks owned by Snom Technology GmbH.
All product specications are subject to change without
notication. Snom Technology GmbH reserves the right
to revise and change this document at any time, without
being obliged to announce such revisions or changes
beforehand or after the fact.
Although due care has been taken in the compilation and
presentation of the information in this document, the data
upon which it is based may have changed in the meantime.
Snom therefore disclaims all warranties and liability for
the accurateness, completeness, and currentness of the
information published, except in the case of intention or
gross negligence on the part of Snom or where liability
arises due to binding legal provisions.
Important Information
Follow the instructions in the manual and other
applicable documentation of the device. Save this guide
and do not give the device to third parties without it.
The nameplate is located at the bottom or rear of the
product.
Safety Instructions
• This device is designed for professional use.
• Warning: The product included (ITE) in this manual is
to be connected only to PoE networks without routing to
the outside plant.
• The socket outlet for the power adaptor must be near
the equipment and easily accessible.
• Mount the device only at heights not exceeding 2m.
• If the phone is not supplied with power via the Ethernet
cable, use only the power adapter listed in the user
instructions. Other power supplies may damage or
destroy the phone, aect its behavior, or induce noise.
• Avoid placing the cables where people may trip over
them or where they may be exposed to mechanical
pressure as this may damage them.
• This device is for indoor use only! NOT FOR OUTDOOR USE!
• Do not install the device in rooms with high humidity (for
example, in bathrooms, laundry rooms, damp basements).
Do not immerse the device in water and do not spill or
pour liquids of any kind onto or into the device.
• Do not install the device in surroundings at risk for
explosions (paint shops, for example). Do not use the device
if you smell gas or other potentially explosive fumes.
• Do not use the device during thunderstorms. Lightning
striking the power grid may cause electric shocks.
• Warning: The handset contains a magnet, and its
earpiece may attract small dangerous objects such as
needles or pins. Please ensure before each use that no
such objects are present.
• SELV (Safety Extra Low Voltage) Compliance. Safety
status of Input/Output connections comply with SELV
requirements. Warning: To avoid electric shock, do
not connect safety extra-low voltage (SELV) circuits to
telephone-network voltage (TNV) circuits. LAN ports
contain SELV circuits, and PSTN ports contain TNV
circuits. Some LAN and PSTN ports both use RJ-45 (8P8C)
connectors. Use caution when connecting cables.
• Caution: To maintain compliance with radio frequency
exposure requirements, the phone shall be installed and
used so that parts of user’s body other than hands keep
a distance of 20 cm or more.
Standards conformance
This device complies with Directive 2014/53/EU
and the essential health, safety, and environ-
mental requirements of all relevant European
directives. This device complies with the Radio
Equipment Regulations 2017 and the essential
health, safety, and environmental standards of the UK.
You can download the declaration of conformity at www.
snom.com/conformity.
Unauthorized opening, changing, or modifying the device
will cause the warranty to lapse and may also result in the
loss of CE and IC conformity and the FCC certication. In
case of malfunction contact authorized service personnel,
your seller, or Snom.
This device is FCC certied and meets US health, safety,
and environmental standards.
FCC ID: EW780-S212-00
This product meets the applicable Innovation, Science and
Economic Development Canada technical specications.
IC: 1135B-80S21200
HVIN: 35-400509BS
FCC part 15
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at the user’s expense.
WARNING: Changes or modications to this equipment not
expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Privacy of communications may not be ensured when
using this telephone.
RF Radiation Exposure
This VoIP Phone complies with FCC RF radiation exposure
limits set forth for an uncontrolled environment.
Caution: To maintain compliance with the radio frequency
exposure requirement, the phone shall be installed and
used so that parts of user’s body other than hands keep a
distance of 20 cm or more.
Consumer Information
a. This equipment complies with Part 68 of the FCC
rules and the requirements adopted by the ACTA. On
the bottom of this equipment is a label that contains,
among other information, a product identier in the
format US:AAAEQ##TXXXX. If requested, this number
must be provided to the telephone company.
b. An applicable certication jacks Universal Service
Order Codes (USOC) for the equipment is provided (i.e.,
RJ45C) in the packaging with each piece of approved
terminal equipment.
c. A plug and jack used to connect this equipment to
the premises wiring and telephone network must
comply with the applicable FCC Part 68 rules and
requirements adopted by the ACTA. A compliant LAN
cable (RJ45) and modular plug is provided with this
product. An RJ45 jack should normally be used for
connecting to the SIP equipment through the LAN
cable. See installation instructions for details.
d. If this equipment causes harm to the telephone
network, the telephone company will notify you in
advance that temporary discontinuance of service may
be required. But if advance notice isn‘t practical, the
telephone company will notify the customer as soon as
possible. Also, you will be advised of your right to le a
complaint with the FCC if you believe it is necessary.
e. The telephone company may make changes in its
facilities, equipment, operations or procedures
that could aect the operation of the equipment. If
this happens the telephone company will provide
advance notice in order for you to make necessary
modications to maintain uninterrupted service.
f. Should you experience trouble with this equipment,
please contact
Snom Technology GmbH
1 (339) 227-6160 (select option 2)
for repair or warranty information. If the equipment is
causing harm to the telephone network, the telephone
company may request that you disconnect the
equipment until the problem is resolved.
g. Please follow instructions for repairing if any
(e.g. battery replacement section); otherwise do
not alternate or repair any parts of device except
specied.
h. Connection to party line service is subject to state
taris. Contact the state public utility commission,
public service commission or corporation commission
for information.
i. NOTICE: If your home has specially wired alarm
equipment connected to the telephone line, ensure
the installation of this device does not disable your
alarm equipment. If you have questions about what
will disable alarm equipment, consult your telephone
company or a qualied installer.
j. This equipment is hearing aid compatible.
NOTICE: According to telephone company reports, AC
electrical surges, typically resulting from lightning strikes,
are very destructive to telephone equipment connected to
AC power sources. To minimize damage from these types
of surges, a surge arrestor is recommended.
Industry Canada
This Class A digital apparatus complies with Canadian
requirements: CAN ICES-003 (A)/NMB-003(A).
This device contains licence-exempt transmitter(s)/
receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including
interference that may cause undesired operation of the
device.
Privacy of communications may not be ensured when
using this telephone.
The term ‘’IC:‘’ before the certication/registration number
only signies that the Industry Canada technical speci-
cations were met. This product meets the applicable
Innovation, Science and Economic Development Canada
technical specications.
RF Radiation Exposure
This VoIP phone also complies with Industry Canada
RSS-102 with respect to Health Canada’s Safety Code 6 for
human exposure to radiofrequency electromagnetic energy.
To maintain compliance with the radio frequency exposure
requirement, the phone shall be installed and used so that
parts of user’s body other than hands keep a distance of
20 cm or more.
Technical specications
• Safety: IEC 62368-1
• Wireless LAN (WLAN, WiFi): 802.11b/g/n/a/ac
◦ Radio frequency (RF) bands:
EMEA: 2412–2472 MHz, 5150–5850 MHz
US: 2412–2462 MHz, 5150–5850 MHz
◦ Max. transmission power:
2.4G Wi-Fi: 18dBm (U.S. & EMEA)
5G Wi-Fi B1: 16dBm (U.S. & EMEA)
5G Wi-Fi B2: 16dBm (U.S. & EMEA)
5G Wi-Fi B3: 16dBm (U.S. & EMEA)
5G Wi-Fi B4: 16dBm (U.S. & EMEA)
• Connectors:
◦ 2 x RJ45 (Ethernet): 1 x LAN, 1 x PC
◦ 2 x 4P4C (handset, optional headset)
◦ 1 x RJ12 (for EHS)
◦ 2 x USB 2.0 ports type A
◦ 1 x 5V DC power jack
• Ethernet: 2 x IEEE 802.3 / 1 Gigabit Ethernet switch
• Power over Ethernet (PoE): IEEE 802.3af, Class 3
If PoE is not available, use the separately available
power adapter (not included in delivery): Mass Power,
model NBS12E050200UV,
◦ With EU and UK clip: Snom PN 00004570
◦ U.S./Canada: shipped with U.S. clip
Disposal of the device
This device is subject to European Directive
2012/19/EU and may not be disposed of with
general household garbage. If you
do not know where to dispose the device at the end of its
lifespan, contact your municipality, local waste manage-
ment provider, or vendor.
For countries outside the European Union
Disposal of electrical and electronic products in countries
outside the European Union should be done in line with lo-
cal regulations. Please contact local authorities for further
information.
Cleaning
To clean the device, use an anti-static cloth. Please avoid
cleaning liquids as they might damage the surface or inter-
nal electronics of the device.
Setting up and connecting the phone: See gures
B, C, and D.
Please note that the cover of the display (Fig. F) is held in
place magnetically for easy removal, if necessary for cus-
tomization or replacement. If the protective lm covering
it is peeled o with too much force, the cover may become
dislodged from the display. Simply put it back into its proper
position.
Initializing and registering the phone
NOTE: You will need the registration information
received from your Internet service provider or
your network administrator - normally the phone or
extension number, the password, and the registrar.
After you have set up the phone and connected it to
the network, it will begin to initialize. Normally the
initialization is completely automatic, using DHCP.
If your network does not support DHCP, you must obtain
the IP address, netmask, IP gateway, and DNS server
from your Internet service provider or your network
administrator and enter them manually.
When the phone has been connected, it will show the
Watch the display and, when prompted, select an option
by pressing the up or down arrow on the navigation
key (Fig. F). Save your selection by pressing the OK key .
1. Language. The default is English.
2. Time zone. Press the function key underneath /
to go to the next/previous time zone, then to
show all available options within that time zone.
3. Tone scheme (dial tone)
4. The display shows the "Welcome" screen. Press
any key to log on. Alternatively, you can also use the
phone's web interface to continue the registration; the
web interface's url is shown on the welcome screen.
5. Enter the account number. Press to save.
6. Enter the registrar. Press to save.
7. If required, enter the password received from your
Internet service provider or administrator. Press
to save.
After successful registration you will see the idle screen
(Fig. E).
For further information, please see our web page
https://service.snom.com.
DEUTSCH
Copyright, Markenrechte, Haftungsausschluss
© 2024 Snom Technology Aktiengesellschaft. Alle Rechte
reserviert.
Snom sowie die Namen der Snom-Produkte und die
Snom-Logos sind gesetzlich geschützte Marken der Snom
Technology GmbH.
Produktspezikationen können ohne Vorankündigung
geändert werden. Snom Technology GmbH behält sich je-
derzeit das Recht auf Überarbeitung und Änderung dieses
Dokumentes vor, ohne verpichtet zu sein, die vorgenom-
menen Änderungen anzukündigen oder mitzuteilen.
Trotz der angewandten Sorgfalt bei der Zusammenstel-
lung und Präsentation der Informationen in diesem Doku-
ment können sich Daten zwischenzeitlich geändert haben.
Daher übernimmt Snom keine Gewähr für die Richtig-
keit, Vollständigkeit oder Aktualität der zur Verfügung
gestellten Informationen. Jegliche Haftung für Schäden
ist ausgeschlossen, sofern diese nicht auf Vorsatz oder
grober Fahrlässigkeit auf seiten von Snom beruhen oder
sofern keine Haftung aufgrund zwingender gesetzlicher
Bestimmungen eintritt.
Wichtige Hinweise
Lesen Sie bitte vor Inbetriebnahme die Sicherheitshin-
weise und die Bedienungsanleitung. Lassen Sie sie auch
von den Mitbenutzern des Gerätes Bewahren Sie dieses
Dokument auf und geben Sie das Telefon nur mit ihm an
Dritte weiter.
Das Typenschild bendet sich unten oder hinten am Gerät.
Sicherheit
Befolgen Sie die Anweisungen in dieser Bedienungsanlei-
tung und in der sonstigen Dokumentation des Geräts.
• Dieses Gerät ist für die beruiche Nutzung bestimmt.
• Warnung: Das in diesem Handbuch enthaltene
Produkt (ITE) darf nur an PoE-Netzwerke ohne
Routing zur Außenanlage angeschlossen werden.
Die Steckdose für das Netzteil muss sich in der Nähe des
Geräts benden und leicht zugänglich sein.
• Montieren Sie das Gerät nur in Höhen von höchstens 2 m.
• Falls die Stromversorgung nicht über ein Ethernetkabel
erfolgt, verwenden Sie nur ein von Snom ausdrücklich
empfohlenes Netzteil. Die Verwendung anderer Netztei-
le könnte das Telefon beschädigen oder gar zerstören.
• Verlegen Sie die Netz- und Stromkabel so, dass sie
durch mechanischen Druck nicht beschädigt werden
und Personen nicht darüber stolpern könnten.
• Dieses Gerät ist nur für den Gebrauch in Innenräumen
bestimmt - NICHT FÜR DEN AUSSENBEREICH!
• Stellen Sie das Gerät nicht in Räumen mit hoher Luft-
feuchtigkeit wie Badezimmern, Waschküchen, feuchten
Kellerräumen auf. Tauchen Sie das Gerät nicht in Wasser
und gießen Sie keine Flüssigkeiten auf oder in das Gerät.
• Stellen Sie das Gerät nicht in explosionsgefährdeten
Umgebungen (z.B. Lackiereien) auf. Benutzen Sie das
Gerät nicht, wenn Sie Gas oder andere möglicherweise
explosionsgefährliche Dämpfe riechen.
• Telefonieren Sie nicht während eines Gewitters (Strom-
schlaggefahr bei Blitzeinschlag ins Netz).
• Warnung: Der Hörer enthält einen Magneten und kann
kleine gefährliche Objekte wie Nadeln anziehen. Bevor
Sie ihn ans Ohr halten, vergewissern Sie sich, dass
keine Objekte daran haften.
• SELV (Safety Extra Low Voltage) Einhaltung. Die
Eingangs-/Ausgangsverbindungen halten die SELV-
Richtlinien für Kleinspannungsgeräte ein. Warnung:
Nur an LAN-Ports anschließen! Um elektrische Schläge
zu vermeiden, verbinden Sie keine SELV-Geräte mit
Geräten, die Telefon-Netzspannung (TNV) führen. LAN-
Ports enthalten SELV-Stromkreise, Festnetz-Anschlüsse
dagegen TNV-Stromkreise; beide könnten jedoch Steck-
verbindungen RJ-45 (8P8C) verwenden.
• Vorsicht: Um die Einhaltung der Richtlinie für
Hochfrequenz-Exposition zu gewährleisten, muss das
Telefon so installiert und benutzt werden, dass andere
Körperteile des Benutzers als die Hände einen Abstand
von mindestens 20 cm zu dem Gerät einhalten.
Normkonformität
Dieses Gerät entspricht der Richtlinie 2014/53/
EU und den grundlegenden Gesundheits-,
Sicherheits- und Umweltanforderungen aller
relevanten europäischen Richtlinien. Die Konformitätser-
klärung können Sie auf https://www.snom.com/conformity
herunterladen.
Die eigenmächtige Önung des Geräts sowie Änderungen
und Modizierungen am Gerät führen zum Erlöschen der
Herstellergarantie und können darüberhinaus zum Erlö-
schen der Zulassungen führen.
Technische Details
v2024001
VoIP phone
D815W
B
Attaching the Footstand · Fuß montieren · Attacher le pied · Montaje el soporte · Fissare il supporto
A
Delivery content · Lieferumfang · Contenu de la boîte · En la caja · Contenuto della confezione
(Bitte Blatt umdrehen, weiter auf der Rückseite)
GNU
General Public License
Quick Installation
Guide
D815W
1 2 3
Snom Technology GmbH
Aroser Allee 66
13407 Berlin, Deutschland
oce.de@snom.com
Snom Technology GmbH
Via Milano 1
20020 Lainate, Italia
oce.it@snom.com
Snom Technology GmbH
130, avenue Joseph Kessel
78960 Voisins-le-Bretonneux, France-
oce.fr@snom.com
Snom Technology GmbH
The Courtyard
High Street
Ascot, Berkshire SL5 7HP, UK
oce.uk@snom.com
VTech Communications Inc.
Snom Americas
9020 Washington Square Road,
Suite 555
Tigard, OR 97223
Phone support: (339) 227 6160
VTech Technologies Canada Ltd.
Suite 222
13888 Wireless Way
Richmond, B.C. V6V 0A3, Canada
Phone support: (339) 227 6160
Manufacturer:
VTech Telecommunications Ltd.
23/F., Tai Ping Industrial Centre,
Block 1,
57 Ting Kok Road, Tai Po
HONG KONG
D
⋅ Peel o gently
⋅ Behutsam abziehen
⋅ Décoller délicatement
⋅ Staccare delicatamente
⋅ Despegar con cuidado
(2, 3)
(1, 2)
(2, 3)
1
2
3
(2, 3)
(2, 3)
USB 2.0 type A
USB 2.0,
type A
• The display is not tiltable.
• The footstand can be
attached at two angles
(one angle when a D8C
expansion module is
connecteF).
E
F
Accept call, conrm
(denoted as in text)
End call, cancel
Produkspesifikasjoner
| Merke: | Snom |
| Kategori: | Ikke kategorisert |
| Modell: | D815W |
Trenger du hjelp?
Hvis du trenger hjelp med Snom D815W still et spørsmål nedenfor, og andre brukere vil svare deg
Ikke kategorisert Snom Manualer
11 Oktober 2025
6 Oktober 2025
6 Oktober 2025
5 Mars 2025
5 Mars 2025
6 Januar 2025
6 Januar 2025
6 Januar 2025
6 Januar 2025
6 Januar 2025
Ikke kategorisert Manualer
- Solis
- Blonder Tongue
- Motorola
- Celexon
- Brinno
- Pentax
- Akai
- Brennenstuhl
- GBC
- Delonghi
- Roccat
- CTA Digital
- Luxli
- Really Right Stuff
Nyeste Ikke kategorisert Manualer
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
