Operation Manual

USB AUDIO INTERFACE

Main features

UR44C Operation Manual 2

Contents

Main features ............................................2

Panel Controls and Terminals ................3

Front Panel ..........................................................3

Rear Panel ...........................................................5

Software ....................................................6

Yamaha Steinberg USB Driver ............................6

dspMixFx UR-C....................................................8

Dedicated Windows for Cubase Series .............13

Sweet Spot Morphing Channel Strip ..................16

REV-X ................................................................18

Guitar Amp Classics ..........................................20

Using with a Computer ..........................23

Connection Example..........................................23

Configuring Audio Driver Settings on the DAW

Software.............................................................24

Recording/Playback ...........................................25

Using with an iOS Device ......................27

Connection Example..........................................27

Recording/Playback ...........................................28

Troubleshooting.....................................30

Appendix.................................................33

Limitations on the use of effects ........................33

Computer connector types.................................33

Signal Flows.......................................................34

Block Diagrams ..................................................35

Technical Specifications ....................................37

General Specifications .......................................38

Uninstalling TOOLS for UR-C ............................39

Main features

6 x 4 USB 3.0 Audio Interface with 4 x

D-PRE and 32-bit/192 kHz support

The UR44C is a 6-in and 4-out USB 3.0 audio

interface, featuring four world-renowned D-PRE

microphone preamps and supporting 192 kHz and

32-bit audio quality to capture all the subtleties and

expressiveness of any audio source.

True 32-bit resolution

The UR44C and the Yamaha Steinberg USB Driver

support the 32-bit Integer format which can

represent audio data in higher resolution compared

to Float format. Together with a DAW (such as

Cubase) which can fully utilize the 32-bit Integer

data, they enable unprecedented audio resolution in

your music production.

USB 3.0 & USB Type-C

The UR44C is equipped with a USB Type-C port and

features USB 3.0 (USB 3.1 Gen 1) SuperSpeed

mode while providing full compatibility with the

USB 2.0 High-Speed mode. The USB Type-C

connection provides enough bus power to operate

the UR44C.

dspMixFx

The dspMixFx technology is powered by the latest

SSP3 DSP chip and offers latency-free monitoring

with highly acclaimed DSP effects, including REV-X

reverb, for users of any DAW software.

Panel Controls and Terminals

UR44C Operation Manual 3

Panel Controls and Terminals

Front Panel

1 [MIC/HI-Z 1/2] jacks

For connection to a microphone, electric guitar, or electric

bass. This jack can be connected to both XLR-type and

phone-type (unbalanced only) plugs. The XLR-type is MIC

only and the phone type is HI-Z only.

NOTE

• The signal is not input when connecting balanced phone-type

plugs.

• The phantom power will be supplied to the XLR jack

connected to the [MIC/LINE 1/2] jacks.

2 [MIC/LINE 3/4] jacks

For connection to a microphone or digital instrument. This

jack can be connected to both XLR-type and phonetype

(balanced/unbalanced) plugs. The XLR type is MIC only

and the phone type is LINE only.

NOTE

The phantom power will be supplied to the XLR jack connected

to the [MIC/LINE 3/4] jacks.

3 [PEAK] indicator

Lights up according to the input signal. Lights up when

the input signal is 3 dB below the clipping level.

4 [+48V] indicator

Lights up when the [+48V] switch (phantom power) is

turned on.

5 [USB] indicator

Lights up when the power is turned on and the unit is

communicating with the computer or iOS device.

The indicator flashes continuously when the computer or

iOS device does not recognize the device.

6 [INPUT 1 to 4 GAIN] knob

Adjusts the input signal level of the [MIC/HI-Z 1/2] jacks

and [MIC/LINE 3/4] jacks.

7 [+48V] switch

Turns the phantom power on and off. When you turn this

switch on, phantom power will be supplied to the XLR jack

connected to the [MIC/LINE 1/2] jacks. Turn this switch on

when using a phantom powered condenser microphone.

8 [+48V] switch

Turns the phantom power on and off. When you turn this

switch on, phantom power will be supplied to the XLR jack

connected to the [MIC/LINE 3/4] jacks. Turn this switch on

when using a phantom powered condenser microphone.

NOTICE

When using phantom power, observe the following to prevent

noise and possible damage to UR44C or connected

equipment.

• Do not connect or disconnect any devices while the

phantom power switch is turned to ON.

• Set all output level controls to the minimum before turning

the phantom power switch to ON or OFF.

• When connecting devices not requiring phantom power to

the [MIC/HI-Z 1/2] and [MIC/LINE 3/4] jacks, make sure to

turn the phantom power switch to OFF.

NOTE

When the phantom power switch is turned on and off, all inputs/

outputs will be muted for a few seconds.

43 3

43 3 5 7 8

6 )

Plug types

Proper use of the HI-Z or LINE inputs

HI-Z

Guitar and bass with passive pickups (not battery

powered)

LINE

• Effect device, preamp, direct box

• Guitar and bass with active pickups (battery

powered)

• Digital instruments, such as synthesizer

Setting optimum recording levels

Adjust the [INPUT GAIN] knobs so that the [PEAK]

indicator flashes briefly at the loudest input volume.

XLR-type (balanced)

Phone-type (balanced)

Phone-type (unbalanced)

Produkspesifikasjoner

Merke:	Steinberg
Kategori:	Hi-fi system
Modell:	UR44C
Vekt:	1500 g
Bredde:	252 mm
Dybde:	159 mm
Høyde:	47 mm
MIDI inn:	Ja
Bitrate:	32 bit
Produktfarge:	Sort
Hodetelefon ut:	Ja
Modell/Type:	Forforsterker
Kroppsmateriale:	Metall
MIDI-utgang:	Ja
Korrekt bruk:	Konsert/studio
Prøvehastighet:	192 kHz
Main ut:	4
