Side 1/20

700TVL

Day / Night Camera

INSTRUCTION MANUAL

M700TVL_150114T

Before you begin

Introduction

Congratulations on your purchase of this indoor/outdoor day & night CCTV camera 700TVL

from Swann. The 700TVL Day/Night Camera is a color camera that can operate in almost

all lighting conditions, from bright daylight (provided it’s not pointed straight toward the

sun!) to pitch darkness.

The 700TVL is very sensitive to light and therefore can make use of even the smallest

amount of light to provide an image of what it sees. In low light, this comes through as a

black and white image.

In complete or near-total darkness, the camera uses built-in infrared LEDs to illuminate

the area in front of it. This light is invisible to the human eye, although you might notice a

faint red glow coming from the front of the camera - this is normal.

In day or well lit environments, the IR Cut Filter feature of the camera activates to filter out

wavelengths of light the camera does not need in order to provide a clear color image.

IMPORTANT NOTE

All jurisdictions have specific laws and regulations relating to the use of cameras. Before

using any camera for any purpose, it is the buyer’s responsibility to be aware of all

applicable laws and regulations that prohibit or limit the use of cameras and to comply with

the applicable laws and regulations.

WARNING

Modifications not approved by the party responsible for compliance could void user’s

authority to operate the equipment.

IMPORTANT SAFETY INSTRUCTIONS

• Make sure product is fixed correctly and stable if fastened in place

• Do not operate if wires and terminals are exposed

ENGLISH

Connection Guide

Connect the camera’s DC and BNC socket

cable to the extension cable’s DC and BNC

plugs. Then connect the BNC extension

cable to an open channel on the back of

the DVR.

For a single camera:

Connect the extension cable’s

DC socket to the DC plug on

the power adapter.

For 2 & 4 camera packs:

Connect the extension cable’s DC

socket to the multiple sockets on the

power splitter. Then, plug the single

end of the power splitter to the DC

plug on the power adapter.

Positioning the Cables

• When running your cable, try to avoid bending it at sharp angles.

• Don’t put your cable near live electrical wiring. AC electricity generates radio

“noise” which can interfere with the signal from your camera.

Produkspesifikasjoner

Merke:	Swann
Kategori:	Sikkerhetskamera
Modell:	PRO-735
Vekt:	305 g
Bredde:	53 mm
Dybde:	85 mm
Høyde:	96 mm
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Infrarød bølgelengde:	850 nm
Antall TV-linjer:	700
Dag/natt-modus:	Ja
NTSC-oppløsninger:	720 x 480 piksler
PAL-oppløsninger:	720 x 576 piksler
Synsfelt:	59 °
Sensortype:	CMOS
Produktfarge:	Sort
Monteringssett:	Ja
Kabler inkludert:	BNC
Driftstemperatur (T-T):	-20 - 50 °C
nattsyn:	Ja
Formfaktor:	Kule
Kroppsmateriale:	Aluminium
Internasjonal beskyttelses (IP)-kode:	IP67
Minimumsbelysning:	0 lx
Støttede plasseringer/plasseringer som kan benyttes:	Inne & Ute
Montasjetype:	Tak/Vegg
Effektiv distanse for nattsyn:	25 m
BNC-utgangsporter:	1
Objektivdiameter:	3.6 mm
Antall lysende LED:	36
Levetid for infrarød LED:	10000 timer
