Side 1/12

Owner’s Manual

HDMI + IR Control

over Cat5 Extender Kit

Model: B126-1A1-IR

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

16-03-172-9334FF.indd 1 3/23/2016 9:18:50 AM

Package Includes

Optional Accessories

• Transmitter and Receiver Units

• IR-TX and IR-RX Cables

• Screwdriver for Equalization Adjustment

• (x2) External Power Supplies with 1-15P Plugs

(Input: 100-240V, 50/60Hz; 0.5A Output: 5V, 2A)

• (x2) Mounting Hardware Kits

• Owner’s Manual

• N202-Series Cat6, 24 AWG Solid Wire Patch Cables

• P568-Series High Speed HDMI Cables

• P569-XXX-LOCK* High Speed HDMI Cables with Ethernet and Locking

Connectors

• B110-INT International AC Adapter

* Available in lengths up to 15 ft., with XXX referring to length

(e.g. 015 = 15 ft., 006 = 6 ft., etc.)

16-03-172-9334FF.indd 2 3/23/2016 9:18:50 AM

Product Features

• Extends a 1080p (60 Hz) signal up to 125 ft. (38 m) from the source

• IR Remote Control functionality lets you control your Blu-ray™ player from

the extended monitor

• Features an additional HDMI port on the transmitter unit for connecting a

local monitor

• Supports 7.1 channel surround sound audio

• Receiver unit features built-in Equalization control for video image

adjustment

• 3D ready and HDCP compatible

• Includes mounting hardware that allows both the transmitter and receiver

units to be wallmounted, rackmounted or pole mounted

• Plug-and-play; no software or drivers required

16-03-172-9334FF.indd 3 3/23/2016 9:18:50 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Mottaker
Modell:	B126-1A1-IR
Bruksanvisning:	Ja
Maksimal oppløsning:	1600 x 1200 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	820 g
HDCP:	Ja
Fargedybde:	24 bit
HDMI inn:	2
Antall HDMI-utganger:	1
Produktfarge:	Sort
Pakkedybde:	55.9 mm
Pakkehøyde:	214.1 mm
Pakkebredde:	165.1 mm
Støttede grafikkoppløsninger:	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1440 x 900 (WXGA+)
Kabler inkludert:	IR
Støttede videofunksjoner:	480i, 480p, 720p, 1080i, 1080p
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	1
DC-inngangskontakt:	Ja
Lyd-utgang kanaler:	7.1 kanaler
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332191325
Masterkassens (ytterkassens) bruttovekt:	8270 g
Masterkassens (ytterkassens) lengde:	227.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	175 mm
Masterkassens (ytterkassens) høyde:	573 mm
Maksimal overføring avstand:	61 m
Kabeltyper som støttes:	Cat5e, Cat6
RJ-45-utgangsporter:	1
