Owner’s Manual

Audio/Video with RS-232

and IR Control over IP Extenders

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Extender Kit Models:

B160-101-DPSI

B160-101-DPHDSI

B160-101-HDSI

B160-103-HDSI

B160-201-HSI

B160-202-HDSI

B160-301-HDSI

Transmitter Models:

B160-001-CSI

B160-001-DPSI

B160-001-HDSI

B160-001-VSI

Receiver Models:

B160-100-CSI

B160-100-DPSI

B160-100-HDSI

B160-100-VSI

B160-200-HSI

WARRANTY REGISTRATION

an ISOBAR surge protector in our monthly drawing!

www.tripplite.com/warranty

Español 25 • Français 50 • Русский 75

Package Contents

B160-001-CSI

B160-001-DPSI

B160-001-HDSI

B160-001-VSI

B160-100-CSI

B160-100-DPSI

B160-100-HDSI

B160-100-VSI

B160-200-HSI

B160-101-DPSI

B160-101-DPHDSI

B160-101-HDSI

B160-103-HDSI

B160-201-HSI

B160-202-HDSI

B160-301-HDSI

Transmitter (T),

Receiver (R), Kit (K)

T T T T R R R R R K K K K K K K

External Power Supply 1 1 1 1 1 1 1 1 1 2 2 2 4 2 4 4

IR-In Cable 0 0 0 0 1 1 1 1 1 1 1 1 1 1 2 3

IR-Out Cable 1 1 1 1 0 0 0 0 0 1 1 1 3 1 2 1

3.5 mm to DB9 M/F

Adapter Cable

1 1 0 1 0 0 0 0 0 1 1 0 3 0 2 1

3.5 mm to DB9 M/M

Adapter Cable

0 0 0 0 1 1 0 1 1 1 1 0 1 1 2 3

HDMI to DVI

Adapter Cable

0 0 1 0 0 0 1 0 0 0 1 2 4 0 4 4

Mounting Hardware Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

Owner’s Manual Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y Y

Optional Accessories

• A008-006 Component Video Gold Cable – 6 ft.

• N202-Series Cat6, 24 AWG, Solid-Wire Patch Cables

• NSS-G16D2 16-Port Gigabit L2 Managed Switch with 8-Outlet PDU

• NSS-G24D2 24-Port Gigabit L2 Managed Switch with 12-Outlet PDU

• P502-Series VGA Cables with RGB Coax

• P520-006 RS-232 Serial Extension Cable – 6 ft.

• P561-Series DVI-D Single-Link Cables

• P566-Series HDMI to DVI Adapter Cables

• P568-Series High-Speed HDMI Cables

• P569-XXX-LOCK* High-Speed HDMI Cables with Ethernet and Locking

Connectors

• P580-Series DisplayPort™ Cables

• P583-Series Mini DisplayPort to DisplayPort Cables

*XXX refers to the length, with cables available in 6 ft. (006), 10 ft. (010) and

15 ft. (015) lengths.
