Side 1/40

1-Port Industrial USB 2.0 over

Cat5/Cat6 Extender Kit with

Metal Case and ESD Protection

Models: B203-101-IND, B203-101-IND-ER

4-Port Industrial USB 2.0 over

Cat5/Cat6 Extender Kit with

Metal Case and ESD Protection

Models: B203-104-IND, B203-104-IND-ER

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Owner's Manual

WARRANTY REGISTRATION

an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 9 • Français 17 • Русский 25 • Deutsch 33

20-04-048 933C77-Book.indb 120-04-048 933C77-Book.indb 1 11/4/2021 3:34:35 PM11/4/2021 3:34:35 PM

• The B203-101-IND and the B203-104-IND extend

USB 2.0 signals up to 150 ft. (45 m) from the source

• The B203-101-IND-ER and the B203-104-IND-ER extend USB

2.0 signals up to 330 ft. (100 m) from the source

• The B203-104-IND and B203-104-IND-ER allow you to

connect up to four USB 2.0 devices

• B203-101-IND and B203-104-IND support USB 2.0 data

transfer rates up to 480 Mbps

• B203-101-IND-ER and B203-104-IND-ER support USB 2.0

data transfer rates up to 300 Mbps

• Power over Cable (PoC) technology provides power to

the transmitter unit via Cat5/Cat6 cable

• Backward compatible with USB 1.1

• Plug-and-play; no software or drivers required

• Compatible with all major operating systems

• B203-101-IND, B203-101-IND-ER, B203-104-IND or

B203-104-IND-ER Extender Kit (Transmitter and Receiver)

• DIN Rail Mounts (x2)

• M4 Screws (x4)

• RS-232 Phoenix Adapter

• International Power Supply (Input: 100V to 240V) with Plug

Adapters for North America, Europe, U.K. and Australia

Product Features

Package Includes

20-04-048 933C77-Book.indb 220-04-048 933C77-Book.indb 2 11/4/2021 3:34:35 PM11/4/2021 3:34:35 PM

• N202-Series Cat6 Snagless Patch Cables

• U022-Series USB 2.0 Cables

• UR022-Series Reversible USB 2.0 Cables

• U030-Series USB 2.0 5-Pin Mini-B Cables

• UR030-Series Reversible USB 2.0 5-Pin Mini-B Cables

• U050-Series USB 2.0 Micro-B Cables

• UR050-Series Reversible USB 3.0 Micro-B Cables

Note: Test to make sure that the entire installation works properly before

pulling cables through ceilings or walls.

1. Connect the transmitter unit to an available USB port on your

computer with a USB 2.0 cable.

Optional Accessories

Installation

Package Includes

• Owner’s Manual

20-04-048 933C77-Book.indb 320-04-048 933C77-Book.indb 3 11/4/2021 3:34:35 PM11/4/2021 3:34:35 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Mottaker
Modell:	B203-104-IND
Vekt:	450 g
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Opprinnelsesland:	Taiwan
Pakkevekt:	340 g
Antall USB 2.0-porter:	5
Sertifisering:	RoHS, REACH, CE, FCC NOM, ISO9001
Senderbredde:	62.4 mm
Senderdybde:	27 mm
Senderhøyde:	115.01 mm
Mottakerbredde:	62.4 mm
Mottakerhøyde:	115.01 mm
Produktfarge:	Black, White
Pakkedybde:	164.1 mm
Pakkehøyde:	55.1 mm
Pakkebredde:	260.1 mm
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	0 - 85
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	85176990
Modell/Type:	Sender og mottaker
Kroppsmateriale:	Metall
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Relativ luftfuktighet under drift (H-H):	0 - 85
Overføringshastighet (Mbps):	480 Mbit/s
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332256086
Masterkassens (ytterkassens) bruttovekt:	7900 g
Masterkassens (ytterkassens) lengde:	273 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	573 mm
Masterkassens (ytterkassens) høyde:	175 mm
Maksimal overføring avstand:	46 m
Kabeltyper som støttes:	Cat5, Cat6
RJ45 porter antall (sender):	1
Mottakerdybde:	27 mm
RJ45 porter antall (mottaker):	1
