Side 1/20

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

HDMI Over Cat5

1x2 Extenders

Models: B126-2A1, B126-2A0

Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

Package Contents 2

Product Features 2

Mounting Instructions 4

Standard 1 x 2 Extender Kit Installation 5

1 x 2 Extender Kit with Remote/Repeater Installation 7

Standard Extender/Splitter Installation 10

Extender/Splitter with Remote/Repeater Installation 13

Troubleshooting 17

Warranty & Warranty Registration 19

13-08-043 93-32D0.indd 1 8/28/2013 2:17:35 PM

Package Contents

Product Features

• ExtendsanHDMIsignalto2monitorsupto200ft.fromthesource

over a single Cat5e/6 cable.

• AB126-002orB126-004extender/splittertransmitterunitisrequired

forusewiththeB126-1A01x2receiverunit.

• Extendsa1080p(60Hz)signalupto150ft.fromthesourceusing

Cat6 cabling, or up to 125 ft. using Cat5 cabling.

• Extends a 1080i (60Hz) signal up to 200 ft. from the source using

Cat6 cabling, or up to 175 ft. using Cat5 cabling.

• Use24AWG,solidwireCat5e/6cable,suchasTrippLite’sN202-Series,

toachievemaximumdistanceandresolution.

• FurtherexpandtherangeandnumberofmonitorsbyaddingB126-110

repeater units.

• AdduptothreerepeatersoneachCat5e/6channel,foratotalof4

displays per channel (An Active remote receiver should be the last unit

in a channel).

• A1080p(60Hz)signalcanbeextendedupto125ft.foreachrepeater

addedintoachannel(orupto175ft,fora1080i(60Hz)signalwhen

usingeitherCat5eorCat6cabling).

• Supports24-bitTrueColor(8-bitsperchannel).

• Built-inequalizationcontroltoadjustthevideoimage.

• B126-2A1KitorB126-2A0ReceiverUnit

• ExternalPowerSupply

(Input:100-240V,50/60Hz,0.5AOutput:5V,2A)

• MountingHardware

• ScrewdriverforEqualizationAdjustment

• Owner’sManual

13-08-043 93-32D0.indd 2 8/28/2013 2:17:35 PM

Product Features

• Supports both stereo and 7.1-channel surround sound audio

(7.1-channel surround sound signal will be Multi-Channel or PCM).

• HDCPand3Dcompatible.

• Plugandplay;Nosoftwareordriversrequired.

• Compatiblewithalloperatingsystems.

• Mountinghardwareincluded.

Optional Accessories:

• B126-110–RemoteRepeaterUnit

• N202-SeriesCat624AWG,SolidWirePatchCables

• P568-SeriesHigh-SpeedHDMICables

13-08-043 93-32D0.indd 3 8/28/2013 2:17:35 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Mottaker
Modell:	B126-2A1
Bruksanvisning:	Ja
Maksimal oppløsning:	1920 x 1080 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	760 g
HDMI inn:	1
Antall HDMI-utganger:	3
Driftsspenning:	5 V
AC-inngangsspenning:	100-240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Sort
Pakkedybde:	164.1 mm
Pakkehøyde:	55.1 mm
Pakkebredde:	260.1 mm
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Støttede videofunksjoner:	1080i, 1080p
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	1
Ekstern strømadapter:	Ja
DC-inngangskontakt:	Ja
Strøm:	2 A
Relativ luftfuktighet under drift (H-H):	20 - 90
AC-adapter bunt:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332180732
Masterkassens (ytterkassens) bruttovekt:	7900 g
Masterkassens (ytterkassens) lengde:	273 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	573 mm
Masterkassens (ytterkassens) høyde:	175 mm
Maksimal overføring avstand:	61 m
Kabeltyper som støttes:	Cat5, Cat5e, Cat6
RJ-45-utgangsporter:	1
