Side 1/12

Owner’s Manual

HDMI over Cat5/Cat6

Active Extender

with Built-in 4K Upscaler

Models: B126-1A0-SC4K and B126-1A1-SC4K

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

16-04-210-9335BB-EN.indd 1 5/6/2016 11:43:20 AM

Product Features

• Built-in 4K Upscaler converts a 1080p @ 24 Hz signal to 4K x 2K @

24 Hz and extends it up to 125 ft. from the source

• Converts 480p and 720p signals to 1080p

• B126-1A0-SC4K works with Tripp Lite’s B126-002 or B126-004

extender/splitter transmitter unit (for details on the B126-002 or

B126-004, reference the owner’s manual included with it)

• Additional HDMI port (on B126-1A1-SC4K only) allows for connection of

a local monitor

• 3D and HDCP compliant

• Built-in Equalization Control for adjusting the video image

• Supports stereo and 7.1 channel surround sound audio

• Compatible with all operating systems

• Includes mounting hardware to allow both transmitter and receiver units

to be wall-mounted, rack-mounted or pole-mounted

• Plug-and-play; no software or drivers required

16-04-210-9335BB-EN.indd 2 5/6/2016 11:43:20 AM

Package Includes

Optional Accessories

B126-1A1-SC4K:

• Both Transmitter and Receiver Units

• (x2) External Power Supplies with NEMA 1-15P Plugs

(Input: 100-240V, 50/60 Hz, 0.5A; Output: 5V, 2A)

• (x2) Mounting Hardware Kits

• Screwdriver for Equalization Adjustment

• Owner’s Manual

B126-1A0-SC4K:

• Receiver Unit Only

• External Power Supply with NEMA 1-15P Plug

(Input: 100-240V, 50/60 Hz, 0.5A; Output: 5V, 2A)

• Mounting Hardware Kit

• Screwdriver for Equalization Adjustment

• Owner’s Manual

• N202-Series Cat6 24 AWG, Solid Wire Patch Cables

• P568-Series High-Speed HDMI Cables

• P569-XXX-LOCK High-Speed HDMI Cables with Ethernet and Locking

Connectors; available in lengths from 6 to 15 ft.; XXX refers to the length

(e.g. 006 = 6 ft., 010 = 10 ft., 015 = 15 ft.)

• B110-INT International AC Adapter

System Requirements

• Computer, Blu-ray™ player or other source with HDMI output port

• 4K-capable display with HDMI port

16-04-210-9335BB-EN.indd 3 5/6/2016 11:43:20 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Mottaker
Modell:	B126-1A1-SC4K
Bruksanvisning:	Ja
Maksimal oppløsning:	2560 x 1600 piksler
HDCP:	Ja
3D:	Ja
HDMI inn:	1
Antall HDMI-utganger:	2
Produktfarge:	Sort
Støttede grafikkoppløsninger:	640 x 480 (VGA),800 x 600 (SVGA),1024 x 768 (XGA),1440 x 900,1600 x 1200 (UXGA),1920 x 1200 (WUXGA),1920 x 1440,2048 x 1536 (QXGA),2560 x 1600 (WQXGA)
Støttede videofunksjoner:	480i, 480p, 720p, 1080i, 1080p
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	2
DC-inngangskontakt:	Ja
Kan monteres på vegg:	Ja
Lyd-utgang kanaler:	7.1 kanaler
Monteringsbeslag inkludert:	Ja
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Maksimal overføring avstand:	38 m
Kabeltyper som støttes:	Cat5, Cat6
